18 / 68
16
I – Inboard Mount
O – Outboard Mount
X – Balanced
(tp) – Patented TruPilot Feature
(a) – Unequally spaced exciter ring mounting
(b) – Equally spaced exciter ring mounting
(c) – Peripheral mount pilot
(d) – Furnished with set screw holes
(e) – Notched
(f) – For ball seat or hub piloted applications
(o) – OEM captive part number
Active Part Numbers
In Order by Part Number
Active Part Numbers
In Order by Size
Obsolete Part Numbers
In Order by Part Number
Gunite
No.
Drum
Weight
Drum
Mount
Drum
Type
Wheel
Type
Brake Size
Overall
Depth
Width
of Brake
Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Special Information
No.
Size
2602AX 114
I
ABA Spoke
16.50x7.00 8.75 7.43 11.25 12.75
6
0.78
2602X 114
I
ABA Spoke
16.50x7.00 8.75 7.43 11.25 12.75
6
0.65
2603
68
I
AAA Spoke
15.00x5.00 6.53 5.53 9.44
11.00
5
0.65
2603A 68
I
AAA Spoke
15.00x5.00 6.53 5.34
9.44
11.00
5
0.65
2603AX 68
I
AAA Spoke
15.00x5.00 6.53 5.34
9.44
11.00
5
0.65
2603X 68
I
AAA Spoke
15.00x5.00 6.53 5.53 9.44
11.00
5
0.65
2604
75
I
AAA Spoke
15.00x6.00 7.03 6.46 9.44
11.00
5
0.65
2604A 75
I
AAA Spoke
15.00x6.00 7.03 6.46 9.44
11.00
5
0.78
2604AX 75
I
AAA Spoke
15.00x6.00 7.03 6.46 9.44
11.00
5
0.78
2604B 75
I
AAA Spoke
15.00x6.00 7.03 6.46 9.44
11.00
6
0.65
2604BX 75
I
AAA Spoke
15.00x6.00 7.03 6.46 9.44
11.00
6
0.65
2604X 75
I
AAA Spoke
15.00x6.00 7.03 6.46 9.44
11.00
5
0.65
2606
0
I
AFA Spoke
16.50x5.50 6.78 6.03 9.44
11.00
5
0.65
2606X
0
I
AFA Spoke
16.50x5.50 6.78 6.03 9.44
11.00
5
0.65
2607
85
I
AAA Spoke
15.00x6.00 8.15 6.62 11.00 12.50
5
0.65
2607X 85
I
AAA Spoke
15.00x6.00 8.15 6.62 11.00 12.50
5
0.65
2608
84
I
AAA Spoke
15.00x7.00 8.65 7.62 11.00 12.50
5
0.65
2608B 83
I
AAA Spoke
15.00x7.00 8.50 7.46 11.00 12.50 5/6
0.65
2608BX 83
I
AAA Spoke
15.00x7.00 8.50 7.46 11.00 12.50 5/6
0.65
2608X 84
I
AAA Spoke
15.00x7.00 8.65 7.62 11.00 12.50
5
0.65
2612
87
I
AAA Spoke
15.00x7.00
8.15 7.43 11.25 12.75
5
0.65
2612X
87
I
AAA Spoke
15.00x7.00
8.15 7.43 11.25 12.75
5
0.65
2624
95
I
ABA Spoke
16.50x7.00 8.43 7.50 11.25 12.75
5
0.78
2624
95
I
ABA Spoke
16.50x6.00 8.43 7.50 11.25 12.75
5
0.78
2624X 95
I
ABA Spoke
16.50x7.00 8.43 7.50 11.25 12.75
5
0.78
Serviced by 3295AX.
2624X 95
I
ABA Spoke
16.50x6.00 8.43 7.50 11.25 12.75
5
0.78
Serviced by 3295AX.
2625
49
I
AAG Spoke
15.00x4.50 5.93 5.00 11.00 12.50
5
0.65
2625X 49
I
AAG Spoke
15.00x4.50 5.93 5.00 11.00 12.50
5
0.65
2626A 80
I
AAA Spoke
15.00x6.00 8.21
6.50 11.00 12.50
5
0.65
2626AX 80
I
AAA Spoke
15.00x6.00 8.21
6.50 11.00 12.50
5
0.65
2626B 80
I
AAA Spoke
15.00x5.00
7.71
6.00 11.00 12.50
5
0.65
2626BX 80
I
AAA Spoke
15.00x5.00
7.71
6.00 11.00 12.50
5
0.65
2627
47
I
CAG Spoke
15.00x3.50 4.54
4.06 12.25 11.00
6
0.53
2627X 47
I
CAG Spoke
15.00x3.50 4.54
4.06 12.25 11.00
6
0.53
2628A 81
I
AAF Spoke
15.00x7.00 8.25 7.43 11.00 12.50
6
0.78
2628AX 81
I
AAF Spoke
15.00x7.00 8.25 7.43 11.00 12.50
6
0.78
2645
73
I
AAA Spoke
16.50x5.00 6.18 5.50 9.44
11.00
5
0.65
2645X 73
I
AAA Spoke
16.50x5.00 6.18 5.50 9.44
11.00
5
0.65
2647
85
I
ABF Spoke
16.00x6.00 8.37
6.56 11.00 12.50
5
0.65
2647X 85
I
ABF Spoke
16.00x6.00 8.37
6.56 11.00 12.50
5
0.65
2650
83
I
AAA Spoke
16.00x6.00 7.21
6.56 11.25 12.75
5
0.65
2650X 83
I
AAA Spoke
16.00x6.00 7.21
6.56 11.25 12.75
5
0.65
2653
46
I
ACG Spoke
15.00x3.50 6.06 3.93 10.00 11.00
5
0.53
2653X 46
I
ACG Spoke
15.00x3.50 6.06 3.93 10.00 11.00
5
0.53
2658
85
I
AAA Spoke
15.00x7.00
8.15 7.43 9.50 11.25
5
0.78
2658A 84
I
AAA Spoke
15.00x7.00
8.15 7.43 9.50 11.25
10
0.81
2658AX 84
I
AAA Spoke
15.00x7.00
8.15 7.43 9.50 11.25
10
0.81
2658B 84
I
AAA Spoke
15.00x7.00
8.15 7.43 9.50 11.25
5
0.78
2658BX 84
I
AAA Spoke
15.00x7.00
8.15 7.43 9.50 11.25
5
0.78
2658C 84
I
AAA Spoke
15.00x7.00
8.15 7.43 9.50 11.25
6
0.65
2658C 84
I
AAA Spoke
15.00x7.00
8.15 7.43 9.50 11.25
5
0.78
2658CX 84
I
AAA Spoke
15.00x7.00
8.15 7.43 9.50 11.25
6
0.65
