14 / 68
12
I – Inboard Mount
O – Outboard Mount
X – Balanced
(tp) – Patented TruPilot Feature
(a) – Unequally spaced exciter ring mounting
(b) – Equally spaced exciter ring mounting
(c) – Peripheral mount pilot
(d) – Furnished with set screw holes
(e) – Notched
(f) – For ball seat or hub piloted applications
(o) – OEM captive part number
Active Part Numbers
In Order by Part Number
Active Part Numbers
In Order by Size
Obsolete Part Numbers
In Order by Part Number
Gunite
No.
Drum
Weight
Drum
Mount
Drum
Type
Wheel
Type
Brake Size
Overall
Depth
Width
of Brake
Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Special Information
No.
Size
2353C 98
I
ABA Spoke
16.50x7.00
8.18 7.40 9.44
11.00
5/6
0.65
2353CX 98
I
ABA Spoke
16.50x7.00
8.18 7.40 9.44
11.00
5/6
0.65
2353D 98
I
ABA Spoke
16.50x7.00
8.18 7.40 9.44
11.00
6
0.78
2353DX 98
I
ABA Spoke
16.50x7.00
8.18 7.40 9.44
11.00
6
0.78
2353E 98
I
ABA Spoke
16.50x7.00
8.18 7.40 9.44
11.00
6
0.65
2353EX 98
I
ABA Spoke
16.50x7.00
8.18 7.40 9.44
11.00
6
0.65
2353X 98
I
ABA Spoke
16.50x7.00
8.18 7.40 9.44
11.00
5/6
0.65
2360 107
I
ABB Spoke
16.50x7.00
8.71
7.43 11.25 12.75
5
0.65
2360C 107
I
ABB Spoke
16.50x7.00
8.81
7.53 11.25 12.75
5
0.65
2360CX 107
I
ABB Spoke
16.50x7.00
8.81
7.53 11.25 12.75
5
0.65
2360X 107
I
ABB Spoke
16.50x7.00
8.71
7.43 11.25 12.75
5
0.65
2389
50
I
AAG Spoke
16.25x3.50 4.62 4.09 9.75 10.87
5
0.59
2389A 50
I
AAG Spoke
16.25x2.25
4.62 4.09 9.75 10.87
6
0.59
2389AX 50
I
AAG Spoke
16.25x2.25
4.62 4.09 9.75 10.87
6
0.59
2389B 50
I
AAG Spoke
16.25x3.50 4.62 4.09 9.75 10.87
5/6
0.59
2389BX 50
I
AAG Spoke
16.25x3.50 4.62 4.09 9.75 10.87
5/6
0.59
2389X 50
I
AAG Spoke
16.25x3.50 4.62 4.09 9.75 10.87
5
0.59
2392
97
I
AAA Spoke
16.50x6.00 7.56 6.81
11.25 12.75
5
0.65
2392X 97
I
AAA Spoke
16.50x6.00 7.56 6.81
11.25 12.75
5
0.65
2394
35
I
AAE Spoke
15.00x3.00 3.96 3.46 10.00 11.25
5
0.53
Labyrinth seal.
2394X 35
I
AAE Spoke
15.00x3.00 3.96 3.46 10.00 11.25
5
0.53
Labyrinth seal.
2396 109
I
ABA Spoke
16.50x7.00 8.44
7.50 11.25 12.75
6
0.78
2396X 109
I
ABA Spoke
16.50x7.00 8.44
7.50 11.25 12.75
6
0.78
Serviced by 3295AX.
2400
86
I
ADE Spoke
15.00x7.00 9.53 7.50 9.75 11.25
5
0.65
Labyrinth seal.
2400B 86
I
ADE Spoke
15.00x7.00 9.53 7.50 9.75 11.25
10
0.81
Labyrinth seal.
2400BX 86
I
ADE Spoke
15.00x7.00 9.53 7.50 9.75 11.25
10
0.81
Labyrinth seal.
2400X 86
I
ADE Spoke
15.00x7.00 9.53 7.50 9.75 11.25
5
0.65
Labyrinth seal.
2401
79
I
ADE Spoke
15.00x6.00 8.53 6.62 9.75 11.25
5
0.65
Labyrinth seal.
2401B 79
I
ADE
Disc
15.00x6.00 8.53 6.62 9.75 11.25
10
0.81
Labyrinth seal.
2401BX 79
I
ADE
Disc
15.00x6.00 8.53 6.62 9.75 11.25
10
0.81
Labyrinth seal.
2401X
79
I
ADE Spoke
15.00x6.00 8.53 6.62 9.75 11.25
5
0.65
Labyrinth seal.
2406 113
I
ABD Spoke
16.50x7.00 10.12 7.93 11.00 12.50
6
0.78
2406X 113
I
ABD Spoke
16.50x7.00 10.12 7.93 11.00 12.50
6
0.78
2500
87
I
ABA Spoke
16.50x6.00 7.25 6.43 11.25 12.75
5/6
0.65
2500X 87
I
ABA Spoke
16.50x6.00 7.25 6.43 11.25 12.75
5/6
0.65
2507
79
I
ABA Spoke
15.00x7.00 9.00 7.43 11.00 12.50
5
0.65
2507B 79
I
ABA Spoke
15.00x7.00 8.62 7.43 11.00 12.50
5
0.65
2507BX 79
I
ABA Spoke
15.00x7.00 8.62 7.43 11.00 12.50
5
0.65
2507X 79
I
ABA Spoke
15.00x7.00 9.00 7.43 11.00 12.50
5
0.65
2508
73
I
ABF Spoke
15.00x6.00 8.62 6.50 11.00 12.50
5
0.65
2508A 72
I
ABF Spoke
15.00x6.00 8.62 6.50 11.00 12.50 5/6
0.65
2508AX 72
I
ABF Spoke
15.00x6.00 8.62 6.50 11.00 12.50 5/6
0.65
2508X 73
I
ABF Spoke
15.00x6.00 8.62 6.50 11.00 12.50
5
0.65
2509
94
I
ABH Spoke
16.50x7.00
8.71
7.43 11.25 12.75
5
0.78
2509X 94
I
ABH Spoke
16.50x7.00
8.71
7.43 11.25 12.75
5
0.78
2511
67
I
AAF Spoke
15.00x6.00 7.25 6.50 11.00 12.50
5
0.65
2511A 67
I
AAF Spoke
15.00x6.00 7.25 6.50 11.25 12.75
5
0.65
2511AX 67
I
AAF Spoke
15.00x6.00 7.25 6.50 11.25 12.75
5
0.65
2511X
67
I
AAF Spoke
15.00x6.00 7.25 6.50 11.00 12.50
5
0.65
2512
89
I
AAH Disc
16.50x7.00
8.31
7.75 13.50 15.00
10
0.53
2512X
89
I
AAH Disc
16.50x7.00
8.31
7.75 13.50 15.00
10
0.53
2516
67
I
AAA Spoke
15.00x6.00 7.25 6.43 11.25 12.75
5
0.65
