AIR DRYERS
VALVES
VALVE KITS
PART NO.
VALVE TYPE
KIT CONTENTS
APPLICATION
R950012
Regeneration
Diaphragm, Cap,
Compression Spring, Valve
Housing, Capscrews
For dryers with date codes earlier than
2295. For SS1200 and SS1800 models.
R950013
Turbo Cut-Off
Plug, Retainer Ring, Cover,
O-Ring, Compression
Spring, Piston (valve), Lip
Seal
If you are replacing the turbo cut-off
valve on a System Saver 1200E air dryer,
please contact Meritor WABCO at
800-535-5560 for part number
information.
R950014
Purge
O-Rings, Washer, Piston
Assembly, Shims, Spring,
Valve Head, Retainer Ring
Install washer with lip facing piston
seat.
Shims may not be included in this kit.
If not included, they are not required. If
included, they must be installed above
and below the spring. Kit is for use on all
single cartridge dryers with U.S. (NPTF)
ports.
R950015
12-volt Heater
Assembly
Mounting Screws (2),
Wiring Connector, O-ring,
Wire, Heater, Thermostat,
Plastic Retainer, Retainer
Screw
12-volt heater kit for dryers with date
code 0994 and later. For all System Saver
Series Air Dryers.
R950016
24-volt Heater
Assembly
Mounting Screws (2),
Wiring Connector, O-ring,
Wire, Heater, Thermostat,
Plastic Retainer, Retainer
Screw
For all 24-volt System Saver Series Air
Dryers.
R950017
Outlet Check
O-Ring, Valve Body, Com-
pression Spring, Washer,
Retainer Ring
Kit is for use on SS1200 and SS1800 air
dryers with U.S. (NPTF) ports.
R950018
Bypass
O-Rings, Valve Body,
Compression Spring,
Cover, Retainer Ring
Use on dryers with date code 0894 or
earlier. Check date code on dryer before
ordering this kit. The date code appears
on the i.d. tag on the face of the dryer.
For use on SS1200 and SS1800 Models.
R950044
Regeneration
Diaphragm, Cap, Com-
pression Spring, Valve
Housing, Capscrews
For dryers with date codes 2295 and
later. For use with all System Saver
Series Air Dryers
