50 / 105
U.S. 888-725-9355
MeritorPartsOnline.com
3-11
Canada 800-387-3889
AIR DRYERS
VALVES
VALVE KITS
PART NO.
VALVE TYPE
KIT CONTENTS
APPLICATION
R950046
Check
Metal Washers, Banjo Fit-
ting, O-Ring, Econ Valve,
Nut, Compression Spring,
Tube
Use on System Saver Series 1200E single
cartridge air dryers.
R950047
Turbo Cut-Off
Plug, Retainer Ring, Cover,
O-Ring, Compression
Spring, Piston (valve), Lip
Seal
For use with 1200E air dryer with Econ
Valve Kit.
R955047
Purge
O-Rings, Piston Assembly,
Spring, Shim, Valve Body
and Retainer Ring
Shim may not be included with this
kit. If not included, it is not required.
If included, install below compression
spring. For use with all System Saver
Series Air Dryers.
S432 431 924 2
Purge
O-Rings, Piston Assembly,
Spring, Shim, Valve Body
and Retainer Ring
Part numbers 432 431 xxx x and 432 433
xxx x
S432 431 925 2
Check
O-Ring, Valve Body, Com-
pression Spring, Washer,
Retainer Ring
Outlet Check Valve Iit for System Saver
Twin Models
S432 413 929 2
Purge
O-Rings, Piston Assembly,
Spring, Shim, Valve Body
and Retainer Ring
Install washer with lip facing piston
seat. Shims may not be included in this
kit. If not included, it is not required.
S432 431 930 2
Relief
O-ring, Piston Assembly,
spring, Washer, Nut, Plug
Charging Valve Kit for System Saver Twin
Models
IMAGE NOT AVAILABLE
AT TIME OF PRINTING
S432 413 932 2
Turbo Cut-Off
Plug, Retainer Ring, Cover,
O-Ring, Compression
Spring, Piston (valve), Lip
Seal
Turbo Cut-Off Piston design change on
all units with date code of 3108 or later
backwards compatible.
S432 413 934 2
Turbo Cut-Off
Plug, Retainer Ring, Cover,
O-Ring, Compression
Spring, Piston (valve), Lip
Seal
Replaces the turbo cut-off valve on a
System Saver 1200E air dryer
S432 470 921 2
Turbo Cut-Off
Plug, Retainer Ring, Cover,
O-Ring, Compression
Spring, Piston (valve), Lip
Seal
For use with the System Saver 1200+ Air
Dryer
