4 Flange has eight holes equally spaced, dished out for nut clearance for ZF and Voith transmissions.
5 Flange has eight holes equally spaced, dished out for nut clearance for Allison transmission.
FLANGE YOKES — BEARING PLATE
Center to
Face
Yoke Dim.
Across Ears
Pilot
Diameter
M=Male
F=Female
Bolt Circle
Diameter
Bearing
Cap
Diameter
Hole
Diameter
Flange
O.D.
Style
Joint
Angle
Part Number
16N SERIES U-JOINT KIT: CP16NS or M279X
2.75"
5.31"
M-6.62"
6.13"
1.63"
.38"
6.88"
1
22°
16N-2-279
2.75"
5.31"
M-7.75"
7.25"
1.63"
.38"
8.00"
2
22°
16N-2-629
17N SERIES U-JOINT KIT: CP17NS or M280X
3.00"
6.09"
F-6.62"
7.25"
1.94"
.44"
8.00"
1
17NF25
3.00"
6.09"
M-7.75"
7.25"
1.94"
.38"
8.00"
1
22°
17NF20
3.00"
6.09"
M-7.75"
7.25"
1.94"
.40"
8.00"
2
22°
17NF1
3.00"
6.09"
M-7.75"
7.25"
1.94"
.44"
8.00"
1
22°
17N-2-739
3.00"
6.09"
M-7.75"
7.25"
1.94"
.44"
8.00"
1
17NF27
4
3.00"
6.09"
M-7.75"
7.25"
1.94"
.44"
8.00"
1
17NF28
5
Face
to
Face
Bolt Circle
Diameter
Diameter
No.
Spaced
Drum Pilot
Diameter
M=Male
F=Female
Pilot
Diameter
Flange
Thickness
Slot
Width
Kit Mtg.
Holes
Part
Number
92N SERIES U-JOINT KIT: CP92N-DWT, CP92N-HB, CP92N-HWD, or PERMALUBE
2.94"
7.25"
.44"
12
Unequally
M-7.75"
8.13"
.31"
.63"
.50” - 20TH
92NF26
Bolt Holes
