BRAKE FLANGE YOKES — ROUND BEARINGS
Yoke
Dim.
Across
Ears
Brg.
Cap
Dia.
Outbrd
Pilot
Mtg.
Surface
Inbrd
Pilot
Mtg.
Surface
Spline
Size
Ctr.
to
End
Hub
Dia.
Bore
Lgth.
Pilot
Dia.
B. C.
Dia.
Bolt Hole
Size
Joint
Angle
Style
Part Number
141N SERIES U-JOINT KIT: CP141N or CP160X
1.38” -
32
6.65” 2.13” 2.16” 4.19” 1.19” 4.75”
5.16”
4.78” 5.75”
.50” -
13TH
2
141TYSB22-4A
1.50” -
35
5.06” 2.50” 2.00” 4.19” 1.19” 4.73”
3.56”
5.75”
.50” -
13TH
2
22°
141TYSB24-6
6
1.50” -
35
5.06” 2.50” 2.00” 4.19” 1.19” 4.73”
3.56”
5.75”
.50” -
13TH
2
22°
141TYSB24-6A
7
1.75” -
10
5.06” 2.50” 2.00” 4.19” 1.19” 4.73”
3.56”
3.19” 5.75”
.50” -
13TH
1
141NYSB28-4
6
148N SERIES U-JOINT KIT: CP148N or CP188X
1.78” -
34
6.19” 2.56” 2.75” 4.19” 1.38” 3.75”
3.55” 4.75”
.50” -
13TH
1
40°
148NYSB29A
1.78” -
34
6.19” 2.56” 2.75” 4.97” 1.38” 3.75”
3.55” 4.75”
.50” -
13TH
2
148TYSB29-1
1.78” -
34
6.25” 2.56” 2.75” 4.19” 1.38” 6.44”
3.55”
7.25”
.38” -
24TH
2
148TYSB28-11A
6
1.81” -
34
6.19” 2.56” 2.75” 4.19” 1.38” 3.75”
3.05”
3.55” 4.75”
.50” -
13TH
1
40°
148NYSB29
1.81” -
34
6.19” 2.56” 2.75” 4.19” 1.38” 3.75”
3.52” 4.75”
.50” -
13TH
2
148TYSB29-1A
2.00” -
38
6.00” 2.75” 2.13” 4.19” 1.38” 6.45”
4.19”
3.69” 7.25”
.38” -
24TH
2
148TYSB32-2A
6
155N SERIES U-JOINT KIT: CP155N or CP155X
1.50” -
10
4.70” 2.25” 2.00” 4.97” 1.38” 6.44”
3.09” 2.72” 7.25” .41” - DR
2
155TYSB24-5
1.78” -
34
6.25” 2.56” 2.75” 4.97” 1.38”
7.25”
TH
2
155TYSB28-22A
1.78” -
34
6.25” 2.56” 2.75” 4.97” 1.38” 3.75”
3.55” 7.25”
.38” -
24TH
2
155TYSB28-14A
8
1.78” -
34
6.25” 2.56” 2.75” 4.97” 1.38” 6.44”
3.80”
7.25” .41” - DR
2
155TYSB28-40A
1.81” -
34
6.26” 2.56” 2.76” 4.97” 1.38” 3.75”
3.54”
4.75” .50” - TH
2
155TYSB29-1A1
2.00” -
38
5.98” 2.75” 2.13” 4.97” 1.38” 6.44”
4.19” 7.25”
.38” -
24TH
2
155TYSB32-13A
6 Pilot diameter is located on earwork side of flange.
7 Includes drum, capscrews and washers.
8 Pilot diameter is located on earwork side of flange. Flange has eight holes equally spaced.
