U—JOINT KITS — WING TYPE COMBINATIONS
Cross
Length
Cross
Trunnion Dia.
CL to CL Brg.
Bolt Hole
Swing Dia.
Pilot Dia.
Wing Brg.
Hole to Wing
Brg. Hole
Wing &
Round Brg.
Type
Series
Part Number
2.874"
0.615"
1.313"
3.34"
3.13"
2.38"
2LWT/2LWD 2CL
GCP2116*
2.874"
0.615"
1.313"
3.34"
3.13"
2.38"
2LWT/2LWD 2CL
CP2116
3.311"
0.657"
1.438"
3.81"
3.55"
2.75"
2LWT/2HWD 3CBL
CP3121
3.372"
0.657"
1.438"
3.81"
3.55"
2.75"
4LWT
3CL
CP3000
3.372"
0.657"
1.438"
3.81"
3.55"
2.75"
4LWT
3CL
GCP3000*
3.935"
0.773"
1.438"
4.50"
4.23"
3.44"
4HWD
4BL
CP4143X
3.935"
0.773"
1.438"
4.50"
4.23"
3.44"
4HWD
4BL
GCP4143X*
3.999"
0.663"
1.438"
4.50"
4.23"
3.44"
4LWT
4CL
CP4002
3.999"
0.663"
1.438"
4.50"
4.23"
3.44"
4LWT
4CL
GCP4002*
3.999"
0.663"
1.438"
4.50"
4.23"
3.44"
2LWT/2LWD 4CL
CP4101
4.249"
0.819"
1.687"
4.75"
4.52"
3.50"
4LWT
5CL
CP5122
4.249"
0.819"
1.687"
4.75"
4.52"
3.50"
4HWD
5BL
CP5177
4.249”
0.819”
1.687”
4.75”
4.52”
3.50”
4HWD
5C
GCP5177X*
4.249"
0.819"
1.687"
4.75"
4.52"
3.50"
2LWLT/2LWD 5CL
CP5101
4.249”
0.819”
1.687”
4.75”
4.52”
3.50”
2HWD/2DWT 5C
GCP5173X*
4.824"
1.063"
1.938"
5.63"
5.31"
4.27"
4DWT
58WB
CP58WB-DWT
4.824"
1.063"
1.938"
5.63"
5.31"
4.27"
4HWD
58WB
CP58WB-HWD
4.824"
1.063"
1.938"
5.63"
5.31"
4.27"
4HWD
58WB
CP58WB-HWD-PL
13
4.824"
1.063"
1.938"
5.63"
5.31"
4.27"
2HWD/2DWT 58WB
CP58WB-HB
4.824"
1.063"
1.938"
5.63"
5.31"
4.27"
2HWD/2DWT 58WB
CP58WB-HB-PL
13
5.125"
0.819"
1.688"
5.45"
5.53"
4.50"
4DWT
62N
CP62N-DWT
5.248”
0.819”
1.688”
5.45”
5.53”
4.50”
4DWT
62N
GCP62N-DWT
*
5.125"
0.819"
1.688"
5.45"
5.53"
4.50"
2HWD/2DWT 62N
CP62N-HB
5.248"
0.819"
1.688"
5.45"
5.53"
4.50"
2HWD/2DWT 62N
GCP62N-HB*
5.125"
0.819"
1.688"
5.45"
5.53"
4.50"
2HWD/2DWT 62N
CP62N-HB-PL
13
5.125"
0.819"
1.688"
5.45"
5.53"
4.50"
4HWD
62N
CP62N-HWD
5.248”
0.819”
1.688”
5.45”
5.53”
4.50”
4HWD
62N
GCP62N-HWD*
5.125"
0.819"
1.688"
5.45"
5.53"
4.50"
4HWD
62N
CP62N-HWD-PL
13
13 Permalube.
*Pricepoint version U-joint
