U—JOINT KITS — WING TYPE COMBINATIONS
13 Permalube.
15 Contains hardware for drilled yokes
*Pricepoint version U-joint
Cross
Length
Cross
Trunnion
Dia.
CL to CL Brg.
Bolt Hole
Swing Dia.
Pilot Dia.
Wing Brg.
Hole to Wing
Brg. Hole
Wing &
Round Brg.
Type
Series
Part Number
7.597”
1.490”
2.812”
8.63”
8.25”
6.63”
4HWD
92N
CP92N-HWD-PL
13
7.597”
1.490”
2.812”
8.63”
8.25”
6.63”
4HWD
92N
CP92N-70
15
7.597”
1.490”
2.812”
8.63”
8.25”
6.63”
2HWD/2DWT 92N
CP92N-HB
7.600”
1.490”
2.812”
8.63”
8.25”
6.63”
2HWD/2DWT 92N
GCP92N-HB*
7.597”
1.490”
2.812”
8.63”
8.25”
6.63”
2HWD/2DWT 92N
CP92N-HB-PL
13
7.625”
1.043”
1.938”
8.50”
8.13”
6.88”
4DWT
82N
CP82N-DWT
7.768”
1.000”
1.938”
8.50”
8.13”
6.88”
4DWT
82N
GCP82N-DWT*
7.625”
1.043”
1.938”
8.50”
8.13”
6.88”
4HWD
82N
CP82N-HWD
7.768”
1.000”
1.938”
8.50”
8.13”
6.88”
4HWD
82N
GCP82N-HWD*
7.625”
1.043”
1.938”
8.50”
8.13”
6.88”
4HWD
82N
CP82N-HWD-PL
13
7.625”
1.043”
1.938”
8.50”
8.13”
6.88”
4HWD
82N
CP82N-68
15
7.625”
1.043”
1.938”
8.50”
8.13”
6.88”
2HWD/2DWT 82N
CP82N-HB
7.768”
1.000”
1.938”
8.50”
8.13”
6.88”
2HWD/2DWT 82N
GCP82N-HB*
7.625”
1.043”
1.938”
8.50”
8.13”
6.88”
2HWD/2DWT 82N
CP82N-HB-PL
13
7.625”
1.043”
1.938”
8.50”
8.13”
6.88”
2HWD/2DWT 82N
CP82N-7715
7.865”
1.665”
3.500”
8.75”
6.80”
4HWD
J490
R49014
8.062”
1.900”
3.500”
8.75”
6.80”
4HWD
J600
R60014
