SLIP YOKES

Keyway

Set Screw or Pin Hole

Bore

Type

Bore Dia.

Center to

End

Bore

Lgth.

Hub Dia. Width Location

Hole Size

Loc. Viewed

From Hub

End

Distance

from End

of Hub

Part Number

YOKE DIMENSION ACROSS EARS: 2.19” BEARING CAP DIAMETER: 1.31”

Hex

.88"

5.50"

4.19"

1.63"

.25” - 28

TH

9-GAP

1.75"

10N-3-162X

Hex

1.13"

5.50"

4.19"

1.63"

.25” - 28

TH

9-GAP

1.75"

10N-3-32X

Round

.81"

5.50"

4.19"

1.63"

.25"

3-GAP .25” - 28 TH

9-GAP

1.75"

10N-3-23X

Round

.88"

5.50"

4.19"

1.63"

.25"

3-GAP .25” - 28 TH

9-GAP

1.75"

10N-3-33X

Round

1.00"

5.50"

4.19"

1.63"

.25"

9-GAP .25” - 28 TH

9-GAP

1.75"

10N-3-83X

Round

1.13"

5.50"

4.19"

2.00"

.31"

3-GAP .25” - 28 TH

9-GAP

1.75"

10N-3-183X

Round

1.25"

5.50"

4.19"

2.00"

.31"

3-GAP .25” - 28 TH

9-GAP

1.75"

10N-3-163X

SPL-10

1.13"

5.50"

4.19"

1.63"

.25” - 28

TH

9-GAP

1.75"

10N-3-81X

Square

.75"

5.50"

4.19"

1.63"

.25” - 28

TH

9-GAP

1.75"

10N-3-12X

Square

.88"

5.50"

4.19"

1.63"

.25” - 28

TH

9-GAP

1.75"

10N-3-22X

Square

1.00"

5.50"

4.19"

2.00"

.25” - 28

TH

9-GAP

1.75"

10N-3-122X
