SPLINE PLUGS
Spline Length
Effective
Length
Use with Tubing O.D. and
Wall
Tubing Insert
Diameter
End of Spline to
Radius
Nylon Coated
Spline
Part Number
3.00” - 16 SPLINE
4.28"
11.25"
4.50" x .134" (10 GA)
4.24"
10.03"
Yes
18N-40-191
4.28"
11.25"
4.50" x .259" (3 GA)
4.00"
10.03"
Yes
PS48-16-1
4.28"
11.53"
4.50" x .259" (3 GA)
4.00"
10.22"
Yes
PS48-16-16
4.28"
9.47"
4.50" x .134" (10 GA)
4.24"
8.41"
Yes
18N-40-201
4.28"
9.47"
4.50" x .259" (3 GA)
4.00"
8.41"
Yes
PS48-16-19
4.29"
11.25"
4.59" x .180" (7 GA)
4.24"
Yes
PS48-16-5
4.70"
10.13"
4.59" x .180 (7 GA)
4.24"
Yes
25RPL-SLIP
3
4.70"
10.13"
4.59" x .180" (7 GA)
4.24"
Yes
PS48-16-38
3 Slip Yoke Assembly includes 25RLS4l8-1A1S slip yoke, PS48-16-38 spline plug, dust seal, shroud and RPL-Lube-50 grease.
