MERITOR TIRE INFLATION SYSTEM CONTROL BOX COMPONENTS
Part Number
Tube
Length
Description
31314-21
10.50”
Stator & Filter Assembly (1/4” NPT).
Threads into spindle plug.
Part Number
Tube
Length
Description
31317-03
3.50”
Brass Thru-Tee Assembly with Tee Vent
and Shield. Stainless steel tube. For Dual
Tire Applications. Replaces 31315-03,
31316-03.
31317-00
4”
Brass Thru-Tee Assy. with Tee Vent and
Shield. Stainless steel tube. For Dual Tire
Applications. Replaces 31316-00.
31317-04
5”
Brass Thru-Tee Assembly with Tee Vent
and Shield. Stainless steel tube. For Dual
Tire Applications. Replaces 31315-04,
31316-04.
Part Number
Tube
Length
Description
31317-03-S
3.50”
Brass Thru-Tee Assembly with Tee Vent
and Shield. Stainless steel tube. For
Super Single Tire Applications. Replaces
31315-03-S, 31316-03-S.
31317-00-S
4”
Brass Thru-Tee Assembly with Tee Vent
and Shield. Stainless steel tube. For
Super Single Tire Applications.
31317-04-S
5”
Brass Thru-Tee Assembly with Tee Vent
and Shield. Stainless steel tube. For
Super Single Tire Applications.
31317-03-S-
Drive
2” Tee for lift axle.
Part Number
Overall
Length
Description
31364-00
11.50” For wheels 17.50” or smaller.
31363-00
13.50”
Short Flex Hose (Outside Tire). For wheels
larger than 17.50”.
11342-04
NA* 3 PSI Valve core with white band
Part Number
Overall
Length
Description
31374-00
12.50” For wheels 17.50” or smaller.
31373-00
17.00”
Long Flex Hose (Inside Tire). For wheels
larger than 17.50”
11373-05
NA* Gasket for inside wheel end of Flex Hose.
31373-11
11.50”
For 17” or larger dual tires. For use with
Super Single tires.
NA = Not Applicable
