COMPONENTS
Cap Screws
Cap Screws
Part Number
(A)
(B)
(C)
(D)
Across Flats
83150
0.50 5/16”-18 0.50
0.50
83750
0.75 3/8”-16 0.75
0.56
85612
1.75 9/16”-12 1.45
0.81
86222
2.00 5/8”-18 1.50
0.94
87511
(HasAdhesive Patch)
2.25 3/4”-10 1.75
1.12
87521
2.25 3/4”-10 1.75
1.12
96218
(HasAdhesive Patch)
1.75 5/8”-18 1.50
0.94
Nuts
Rim Clamp Nuts
Part Number
(A)
Thread
(B)
Hex
(C)
Height
74710 (Flat Face)
3/4”-10
1.25
0.73
Inner Cap Nuts (Grade 8 for Aluminum Wheels)
Part
Number
Inner
Thread
Outer
Thread
(A)
Square
(B)
Length
(C)
Inner Thread
Depth
105988 (RH)
3/4”-16 1 1/8”-16 0.81 3.06
1.88
105989 (LH)
3/4”-16 1 1/8”-16 0.81 3.06
1.88
Inner Cap Nuts (Grade 8 for Steel Wheels)
107082 (RH)
3/4”-16 1 1/8”-16 0.81 2.24
1.25
107083 (LH)
3/4”-16 1 1/8”-16 0.81 2.24
1.25
