SLACK ADJUSTERS
MERITOR PREMIUM CLEARANCE SENSING AUTOMATIC SLACK ADJUSTERS
STEERING AXLE (NON-DRIVE) APPLICATIONS FOR 15”, 16-1/4” AND 16-1/2” BRAKES
EUCLID KIT
NO.
INCLUDES
BRACKET NO.
ANGLE
STRAIGHT/
OFFSET
SPLINE SIZE ARM LENGTH
BUSHING
I.D.
APPLICATION
M807009 R810302
0°
Straight
1-1/4”-10 5-1/2”
5/8”
Double Bend Control Arm.
Standard Steering Axle Brakes.
Replaces 400-10001, 409-10658
M807010 R810303
0°
Straight
1-1/4”-24 5-1/2”
5/8”
Double Bend Control Arm.
Standard Steering Axle Brakes.
Replaces 400-10004, 409-10659
M807011 R810302
0°
Straight
1-1/2”-10 5-1/2”
5/8”
Double Bend Control Arm.
Standard Steering Axle Brakes.
Replaces 400-10005, 409-10662
M807012 R810302
0°
Straight
1-1/2”-28 5-1/2”
5/8”
Double Bend Control Arm.
Standard Steering Axle Brakes.
Replaces 400-10008, 409-10663
M807025 R810300
16° Straight
1-1/2”-28 5-1/2”
1/2”
Single Bend Control Arm.
Standard Steering Axle Brakes.
Replaces 400-10081, 409-10228
M807502 R810302
22° LH 5/8” 1-1/4”-10 5-1/2”
5/8”
Double Bend Control Arm. For
Standard Steering Axle Brakes
with 5/8” Offset Arm. Replaces
400-10003, 409-10660
M807503 R810302
22° RH 5/8” 1-1/4”-10 5-1/2”
5/8”
Double Bend Control Arm. For
Standard Steering Axle Brakes
with 5/8” Offset Arm. Replaces
400-10002, 409-10661
M807504 R810303
22° LH 5/8” 1-1/4”-24 5-1/2”
5/8”
Double Bend Control Arm. For
Standard Steering Axle Brakes
with 5/8” Offset Arm. Replaces
400-10041, 409-10664
M807505 R810303
22° RH 5/8” 1-1/4”-24 5-1/2”
5/8”
Double Bend Control Arm. For
Standard Steering Axle Brakes
with 5/8” Offset Arm. Replaces
400-10040, 409-10665
M807501 R810304
22° RH 1-1/2” 1-1/2”-28 5-1/2”
1/2”
For Mack 16,000 lb.-Up Steering
Axle Brakes with 1-1/2” Offset
Arm. Replaces 400-10059, 409-
10600
M807500 R810304
22° LH 1-1/2” 1-1/2”-28 5-1/2”
1/2”
For Mack 16,000 lb.-Up Steering
Axle Brakes with 1-1/2” Offset
Arm. Replaces 400-10058, 409-
10599
M807507 R810311
22° LH 5/8” 1-1/2”-28 6”
1/2”
Single Bend Control Arm.
Dina Bus - MCI Steer Axles
Brakes. Replaces 400-10068,
409-10638
M807508 R810314
22° RH 5/8” 1-1/2”-28 6”
1/2”
Single Bend Control Arm.
Dina Bus - MCI Steer Axles
Brakes. Replaces 400-10069,
409-10639
CAUTION:
Do not mix Automatic Slack Adjuster brands on the same vehicle.
