Euclid Air Hose Assembly part numbers consist of a four digit base number followed by a dash and two additional digits. The four digit base number designates
the size of the air hose and type of end fittings. The last two digits designate the overall length of the hose, "A" above. Air hoses are sold unpackaged as
designated by the -BK after each part numbe
r.
EUCLID BASE NO.
AIR HOSE I.D. END FITTING TYPE
E-8579
3/8"
1/4"-18NPTF, one fixed, one swivel end
E-8580
3/8"
3/8"-18NPTF, one fixed, one swivel end
E-8581
3/8"
3/8"-18NPTF, both ends swivel
E-8582
1/2"
3/8"-18NPTF, one fixed, one swivel end
E-8583
1/2"
1/2"-18NPTF, fixed end; 3/8"-18NPTF, swivel end
E-8584
1/2"
3/8"-18NPTF, both ends swivel
3/8” Air Brake Hose Assemblies
1/2” Air Brake Hose Assemblies
Overall Air
Hose Length
“A”
Euclid No.
1/4”-18 NPTF
1 Fixed/1 Swivel
Euclid No.
3/8”-18 NPTF
1 Fixed/1 Swivel
Euclid No.
3/8”18 NPTF 2
Swivel
Euclid No.
3/8”-18 NPTF
1 Fixed/1 Swivel
Euclid No.
1/2”-14 NPTF Fixed
3/8”-18 NPTF Swivel
Euclid No.
3/8”-18 NPTF
2 Swivel
8"
E-8579-08-BK E-8580-08-BK E-8581-08-BK
E-8582-08-BK E-8583-08-BK
E-8584-08-BK
12"
E-8579-12-BK E-8580-12-BK E-8581-12-BK
E-8582-12-BK E-8583-12-BK
E-8584-12-BK
14"
E-8579-14-BK E-8580-14-BK E-8581-14-BK
E-8582-14-BK E-8583-14-BK
E-8584-14-BK
16"
E-8579-16-BK E-8580-16-BK E-8581-16-BK
E-8582-16-BK E-8583-16-BK
E-8584-16-BK
18"
E-8579-18-BK E-8580-18-BK E-8581-18-BK
E-8582-18-BK E-8583-18-BK
E-8584-18-BK
20"
E-8579-20-BK E-8580-20-BK E-8581-20-BK
E-8582-20-BK E-8583-20-BK
E-8584-20-BK
22"
E-8579-22-BK E-8580-22-BK E-8581-22-BK
E-8582-22-BK E-8583-22-BK
E-8584-22-BK
24"
E-8579-24-BK E-8580-24-BK E-8581-24-BK
E-8582-24-BK E-8583-24-BK
E-8584-24-BK
26"
E-8579-26-BK E-8580-26-BK E-8581-26-BK
E-8582-26-BK E-8583-26-BK
E-8584-26-BK
28"
E-8579-28-BK E-8580-28-BK E-8581-28-BK
E-8582-28-BK E-8583-28-BK
E-8584-28-BK
30"
E-8579-30-BK E-8580-30-BK E-8581-30-BK
E-8582-30-BK E-8583-30-BK
E-8584-30-BK
32"
E-8579-32-BK E-8580-32-BK E-8581-32-BK
E-8582-32-BK E-8583-32-BK
E-8584-32-BK
34"
E-8579-34-BK E-8580-34-BK E-8581-34-BK
E-8582-34-BK E-8583-34-BK
E-8584-34-BK
36"
E-8579-36-BK E-8580-36-BK E-8581-36-BK
E-8582-36-BK E-8583-36-BK
E-8584-36-BK
38"
E-8579-38-BK E-8580-38-BK E-8581-38-BK
E-8582-38-BK E-8583-38-BK
E-8584-38-BK
40"
E-8579-40-BK E-8580-40-BK E-8581-40-BK
E-8582-40-BK E-8583-40-BK
E-8584-40-BK
42"
E-8579-42-BK E-8580-42-BK E-8581-42-BK
E-8582-42-BK E-8583-42-BK
E-8584-42-BK
44"
E-8579-44-BK E-8580-44-BK E-8581-44-BK
E-8582-44-BK E-8583-44-BK
E-8584-44-BK
46"
E-8579-46-BK E-8580-46-BK E-8581-46-BK
E-8582-46-BK E-8583-46-BK
E-8584-46-BK
48"
E-8579-48-BK E-8580-48-BK E-8581-48-BK
E-8582-48-BK E-8583-48-BK
E-8584-48-BK
50"
E-8579-50-BK E-8580-50-BK E-8581-50-BK
E-8582-50-BK E-8583-50-BK
E-8584-50-BK
52"
E-8579-52-BK E-8580-52-BK E-8581-52-BK
E-8582-52-BK E-8583-52-BK
E-8584-52-BK
54"
E-8579-54-BK E-8580-54-BK E-8581-54-BK
E-8582-54-BK E-8583-54-BK
E-8584-54-BK
56"
E-8579-56-BK E-8580-56-BK E-8581-56-BK
E-8582-56-BK E-8583-56-BK
E-8584-56-BK
60"
E-8579-60-BK E-8580-60-BK E-8581-60-BK
E-8582-60-BK E-8583-60-BK
E-8584-60-BK
62"
E-8579-62-BK E-8580-62-BK E-8581-62-BK
E-8582-62-BK E-8583-62-BK
E-8584-62-BK
66"
E-8579-66-BK E-8580-66-BK E-8581-66-BK
E-8582-66-BK E-8583-66-BK
E-8584-66-BK
68"
E-8579-68-BK E-8580-68-BK E-8581-68-BK
E-8582-68-BK E-8583-68-BK
E-8584-68-BK
72"
E-8579-72-BK E-8580-72-BK E-8581-72-BK
E-8582-72-BK E-8583-72-BK
E-8584-72-BK
84"
E-8579-84-BK E-8580-84-BK E-8581-84-BK
E-8582-84-BK E-8583-84-BK
E-8584-84-BK
AIR BRAKE HOSE ASSEMBLIES
