11 / 206
1-6
U.S. 888-725-9355
Canada 800-387-3889
HALDEX SERVICE COMPONENTS
BOOT ASSEMBLY
EUCLID NO.
REPLACES
APPLICATION INFORMATION
E-12728
Haldex BA1
For 5/8” push rod
E-2764
Haldex 11M034
MGM 9004001
Used on Severe Service Operations, Gravel Haulers, and Transit Mix
Trucks.
DUST SHIELDS
EUCLID NO.
REPLACES HALDEX NO.
APPLICATION INFORMATION
E-12738
DS1
5/8” push rod, 1” (25.4mm) hole
E-12739
DS2
3/4” push rod, 1” (25.4mm) hole
E-12740
DS3
5/8” push rod, 1.58” (40mm) hole
E-12741
DS4
3/4” push rod, 1.58” (40mm) hole
AIR CHAMBER CLAMPING BOLT AND NUT
EUCLID NO.
REPLACES
THREAD
LENGTH
E-12769
Haldex HW8
3/8”-24
E-2144
3/8”-16
2-1/2”
MOUNTING HARDWARE KITS
EUCLID NO.
REPLACES HALDEX NO.
DESCRIPTION
THREAD SIZE
E-12762
HW1
Lockwasher and standard nut
7/16”-14
E-12763
HW2
Lockwasher and standard nut
5/8”-11
E-12764
HW3
Flat washer and locking nut
5/8”-11
JAM NUTS
EUCLID NO.
REPLACES HALDEX NUMBER
THREAD SIZE
E-12765
HW4
1/2”-20
E-12766
HW5
5/8”-18
E-12767
HW6
M16
E-12768
HW7
3/4”-16
PIPE PLUG FITTING
EUCLID NO.
REPLACES HALDEX NUMBER
THREAD SIZE
E-12770
PP1
3/8”, Square
