CAMSHAFTS
EUCLID CAMSHAFT E.S.P. GUIDE
LENGTH
HEAD
TYPE
SPLINE JRNL. DIA.
EUCLID
NO.
HEAD
END* AXLE CAMSHAFT KIT
MFR./BRAKE SIZE
NOTES
10-13/16” 11 1-1/2”-28 1-1/2”
E-11547
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-11546
RH
10-29/32” 9 1-1/4”-10 1-1/4”
E-5062
LH
S E-5140
Eaton 15”
E-5063
RH
10-15/16” 11 1-1/2”-28 1-1/2
”
E-9657
E-9658
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-5094A (Mack App.),
E-9090 (2-1/2” Offset Spider)
RH
11-1/32”
2 1-1/2”-10 1-1/2”
E-11864
LH
T
E-11897,
E-11450HD
Hendrickson 16-1/2”
Intraax®
E-11865
RH
11-1/32”
2 1-1/2”-28 1-1/2”
E-11866
LH T E-11897,
E-11450HD
Hendrickson 16-1/2”
Intraax®
E-11867
RH
11-1/32”
1 1-1/2”-28 1-1/2”
E-10899
LH
T E-9791HD
Hendrickson 16-1/2”
Intraax®
E-10900
RH
11-1/8”
1 1-1/2”-10 1-1/2”
E-9765
LH
D E-2125
Eaton 16-1/2”
Lock Ring End Dia. - 1-1/8”
E-9766
RH
11-1/8”
11 1-1/2”-10 1-1/2”
E-1774C
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-1773C
RH
11-1/8”
11 1-1/2”-28 1-1/2”
E-9659
E-9660
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-5094A (Mack App.),
E-9090 (2-1/2” Offset Spider)
RH
11-13/64” 11 1-1/2”-28 1-5/8”
E-11619
LH
D E-11904
Meritor 16-1/2” Q Plus
E-11618
RH
11-3/8”
8 1-1/2”-28 1-1/2”
E-11548
LH
S E-3993B
Meritor 15” Q Plus
E-11549
RH
11-1/2”
2 1-1/2”-10 1-1/2”
E-5492
LH
D E-10897
Eaton 15” Reduced
Envelope , 16-1/2” ES
Lock Ring End Dia. - 1-1/8”
E-5493
RH
11-1/2”
1 1-1/2”-10 1-1/2”
E-1776
LH
D E-2125
Eaton 16-1/2”
Lock Ring End Dia. - 1-1/8”
E-1775
RH
11-33/64” 11 1-1/2”-10 1-1/2”
E-1148C
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-1147C
RH
11-9/16” 11 1-1/2”-28 1-1/2”
E-9661
E-9662
LH
D E-9080
Meritor 16-1/2” Q Plus
E-5094A (Mack App.),
E-9090 (2-1/2” Offset Spider)
RH
11-19/32” 8 1-1/2”-28 1-1/2”
E-11550
LH
S E-3993B
Meritor 15” Q Plus
E-11551
RH
11-11/16” 11 1-1/2”-10 1-1/2”
E-4703B
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-4702B
RH
11-11/16” 11 1-1/2”-28 1-1/2”
E-9663
E-9664
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-5094A (Mack App.),
E-9090 (2-1/2” Offset Spider)
RH
*Left or Right Hand description refers to the rotation of the Camshaft Head. This description does not always match the position of the Camshaft on the axle.
AXLE = S-Steering; D-Drive; T-Trailer
