CAMSHAFTS
EUCLID CAMSHAFT E.S.P. GUIDE
LENGTH
HEAD
TYPE
SPLINE JRNL. DIA.
EUCLID
NO.
HEAD
END* AXLE
CAMSHAFT KIT
MFR./BRAKE SIZE
NOTES
16-13/16” 11 1-1/2”-28 1-1/2”
E-11595
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-11594
RH
16-61/64” 11 1-1/2”-28 1-1/2”
E-11597
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-11596
RH
17-3/16”
2 1-1/2”-28 1-1/2”
E-9096
LH
T E-2287
Spicer 16-1/2” XL
Double Groove Journal - 1-5/8”,
2-7/32”
E-9097
RH
17-5/16” 11 1-1/2”-10 1-5/8”
E-2447A
LH
T E-3520A, E-3520AHD Meritor 16-1/2” Q Plus
E-2448A
RH
17-5/16” 11 1-1/2”-28 1-5/8”
E-2441B
LH
T E-3520A, E-3520AHD
Meritor 16-1/2” P, Q, Q
Plus
E-2442B
RH
17-5/16” 11 1-1/2”-28 1-5/8”
E-5506
LH
T
E-9078HD (Press-In
Bushing), E-9079HD
(Bolt-On Bushing)
Meritor 16-1/2” Q Plus
E-5507
RH
17-3/8”
1 1-1/2”-10 1-1/2”
E-2795
LH
T See Camshaft pages Multi-App 16-1/2”
Single Groove Journal
E-2794
RH
17-3/8”
5 1-1/2”-10 1-1/2”
E-9751
LH
T
E-2469 (Nylon
Bushing)
Spicer 12-1/4”
0794L/R Head Fast-Rise
E-9752
RH
17-3/8”
2 1-1/2”-10 1-1/2”
E-5516
LH
T E-2287
Spicer 16-1/2” XL
Double Groove Journal - 1-5/8”,
2-7/32”
E-5517
RH
17-3/8”
1 1-1/2”-28 1-1/2”
E-9725
LH
T E-2287
Spicer 16-1/2”
Double Groove Journal - 1-5/8”,
2-7/32”
E-9726
RH
17-7/16”
2 1-1/2”-28 1-1/2”
E-5522
LH
T E-2287
Spicer 16-1/2” XL
Double Groove Journal - 1-5/8”,
2-7/32”
E-5523
RH
17-7/16”
2 1-1/2”-28 1-5/8”
E-9731
LH
T E-11910, E-9790A Spicer 16-1/2” XL
Single Groove Journal - 2-7/32”
E-9732
RH
17-29/64” 11 1-1/2”-28 1-1/2”
E-11599
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-11598
RH
17-23/32” 11 1-1/2”-10 1-1/2”
E-4715A
LH
D E-3993B
Meritor 16-1/2” Q Plus
See E-4714 & E-4715 for Trailer
Cams
E-4714A
RH
17-3/4”
1 1-1/2”-10 1-1/2”
E-4715
LH
T See Camshaft pages Multi-App 16-1/2” Q Single Groove Journal
E-4714
RH
17-61/64” 11 1-1/2”-28 1-1/2”
E-11601
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-11600
RH
18”
5 1-1/2”-10 1-1/2”
E-9749
LH
T
E-2469 (Nylon
Bushing)
Spicer 12-1/4”
0794L/R Head Fast-Rise
E-9750
RH
18-3/8”
11 1-1/2”-10 1-1/2”
E-689A
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-688A
RH
*Left or Right Hand description refers to the rotation of the Camshaft Head. This description does not always match the position of the Camshaft on the axle.
AXLE = S-Steering; D-Drive; T-Trailer
