CAMSHAFTS
*Left or Right Hand description refers to the rotation of the Camshaft Head. This description does not always match the position of the Camshaft on the axle.
AXLE = S-Steering; D-Drive; T-Trailer
EUCLID CAMSHAFT E.S.P. GUIDE
LENGTH
HEAD
TYPE
SPLINE JRNL. DIA.
EUCLID
NO.
HEAD
END* AXLE
CAMSHAFT KIT
MFR./BRAKE SIZE
NOTES
18-3/8”
1 1-1/2”-10 1-1/2”
E-689
LH
T See Camshaft pages Multi-App 16-1/2” Q Single Groove Journal
E-688
RH
18-29/64” 11 1-1/2”-28 1-1/2”
E-11603
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-11602
RH
18-29/64” 11 1-1/2”-28 1-5/8”
E-11643
LH
D E-11904
Meritor 16-1/2” Q Plus
E-11642
RH
18-19/32” 11 1-1/2”-28 1-1/2”
E-11605
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-11604
RH
18-5/8”
11 1-1/2”-10 1-1/2”
E-2413A
LH
D E-3993B
Meritor 16-1/2” Q Plus
E-2412A
RH
18-5/8”
1 1-1/2”-10 1-1/2”
E-2413
LH
T See Camshaft pages Multi-App 16-1/2” Q Single Groove Journal
E-2412
RH
18-7/8”
5 1-1/2”-10 1-1/2”
E-9265
LH
T
E-2469 (Nylon
Bushing)
Spicer 12-1/4”
0794L/R Head Fast-Rise
E-9266
RH
18-7/8”
3 1-1/2”-10 1-1/2”
E-9743
LH
T
E-2469 (Nylon
Bushing)
Spicer 12-1/4”
Standard Head
E-9744
RH
19-1/2”
2 1-1/2”-10 1-1/2”
E-9739
LH
T E-2287
Spicer 16-1/2” XL
Double Groove Journal - 1-5/8”,
2-7/32”
E-9740
RH
19-1/2”
1 1-1/2”-10 1-5/8”
E-2693
LH
T E-2696A
Eaton 16-1/2”
Trailer Axle
E-2694
RH
19-1/2”
2 1-1/2”-10 1-5/8”
E-5494
LH
T E-2696A
Eaton 16-1/2” ES
E-5495
RH
19-1/2”
2 1-1/2”-28 1-5/8”
E-9057
LH
T E-2696A
Eaton 16-1/2” ES
E-9058
RH
20-7/32”
1 1-1/2”-28 1-5/8”
E-4723
LH
T E-2696A
Eaton 16-1/2”
E-4722
RH
20-5/16”
3 1-1/2”-10 1-1/2”
E-1394
LH
T E-2494
Eaton 12-1/4”
E-1393
RH
20-5/16”
4 1-1/2”-28 1-1/2”
E-10919
LH
T E-2469
Dexter 12-1/4”
Single Groove Journal
E-10920
RH
20-3/8”
1 1-1/2”-10 1-1/2”
E-2107
LH
T See Camshaft pages Multi-App 16-1/2”
Double Groove Journal
E-2108
RH
20-3/8”
1 1-1/2”-10 1-1/2”
E-557
LH
T See Camshaft pages Multi-App 16-1/2”
Double Groove Journal, Full
Length Heat Treat
E-556
RH
20-3/8”
2 1-1/2”-10 1-1/2”
E-5518
LH
T E-2287
Spicer 16-1/2” XL
Double Groove Journal - 1-5/8”,
2-7/32”
E-5519
RH
