CAMSHAFTS
CAMSHAFT REPAIR KITS
E-3993B
For 15” and 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-1113
1 4 Washer
FOR MERITOR 15 and 16-1/2”
DRIVE AXLE “Q” and Q PLUS
BRAKES
Contains E-3859 Rubber
Camshaft Support Gasket.
Contains New Style E-5512
Moly-impregnated Spider
Bushing. Contains Lock Rings for
Camshafts with narrow or wide
grooves.
E-801
2 2 Lock Ring
E-5093
3 2 Camshaft Lock Ring
E-5512
4 4 Camshaft Bushing
E-654
5 4 Camshaft Seal
E-3479
6 4 Camshaft Spacer Washer
E-3478
7 2 Camshaft Wear Washer
E-3859
8 2 Camshaft Seal
E-3993B-2
For 15” and 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-1113
1 2 Washer
FOR MERITOR 15 and 16-1/2”
DRIVE AXLE “Q” and Q PLUS
BRAKES
Contains E-3859 Rubber
Camshaft Support Gasket.
Contains New Style E-5512
Moly-impregnated Spider
Bushing. Contains Lock Rings
for Camshafts with narrow or
wide grooves. Contains half of Kit
E-3993B.
E-801
2 1 Lock Ring
E-5093
3 1 Camshaft Lock Ring
E-5512
4 2 Camshaft Bushing
E-654
5 2 Camshaft Seal
E-3479
6 2 Camshaft Spacer Washer
E-3478
7 1 Camshaft Wear Washer
E-3859
8 1 Camshaft Seal
E-5501
For 15” and 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-536
1 4 Camshaft Bushing
FOR EATON 15” “REDUCED
ENVELOPE” BRAKES AND DRIVE
AXLES WITH 16-1/2” “ES”
“EXTENDED SERVICE” BRAKES
E-1416
2 4 Camshaft Seal
E-1781
3 2 Camshaft Spacer Washer
E-1782
4 2 Camshaft Spacer Washer
E-3234
5 2 Camshaft Snap Ring
E-5482
6 2 Camshaft Wear Washer
E-580
7 2 Camshaft Spacer Washer
E-5501-2
For 15” and 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-536
1 4 Camshaft Bushing
FOR EATON
Self-Contained Drive Axle Brakes
E-1416
2 4 Camshaft Seal
E-580
3 2 Camshaft Spacer Washer
E-1781
4 2 Camshaft Spacer Washer
E-1782
5 2 Camshaft Spacer Washer
E-3234
6 2 Camshaft Snap Ring
E-1780
7 2 Cotter Pin
