CAMSHAFTS
BRAKE CAMSHAFTS — TRAILER AXLE
FOR SPICER TRAILER AXLES WITH 16-1/2” “XL” “XTRALIFE” BRAKES WITH 1-5/8” BEARING JOURNAL
EUCLID NO.
HEAD END
NOMINAL
HEAD DIM.
REPLACES
A
B
CAMSHAFT
REPAIR KIT
BRAKE
REPAIR KIT
GENERAL INFORMATION
E-9731
LH
1-1/8”
Dana/Spicer M16WKL25-175
17-7/16” 2-1/4”
E-5515 (XL)
E-2769HD
(Standard
Q)
E-9790A
E-11910
These cams are “extended life”
versions of this manufacturer’s
“standard version”. If
retrofitting from “standard”
to “extended life” camshafts,
Euclid strongly recommends
replacing both cams on a
single axle or all cams on
tandem axles to promote a
balanced brake condition.
E-9732
RH
Dana/Spicer M16WKR25-175
E-9733
LH
1-1/8”
Dana/Spicer M16WKL25-205
20-7/16” 2-1/4”
E-9734
RH
Dana/Spicer M16WKR25-205
E-11856
LH
1-1/8”
Dana/Spicer M16WKL25-227
22-5/8” 2-1/4”
E-11857
RH
Dana/Spicer M16WKR25-227
E-11858
LH
1-1/8”
Dana/Spicer M16WKL25-231
22-7/8” 2-1/4”
E-11859
RH
Dana/Spicer M16WKR25-231
E-9735
LH
1-1/8”
Dana/Spicer M16WKL25-236
23-9/16” 2-1/4”
E-9736
RH
Dana/Spicer M16WKR25-236
E-10909
LH
1-1/8”
Dana/Spicer M16WKL25-242
24-1/8” 2-1/4”
E-10910
RH
Dana/Spicer M16-WKR25-242
E-11860
LH
1-1/8”
Dana/Spicer M16WKL25-264
26-1/4” 2-1/4”
E-11861
RH
Dana/Spicer M16WKR25-264
E-9737
LH
1-1/8”
Dana/Spicer M16WKL25-271
26-15/16” 2-1/4”
E-9738
RH
Dana/Spicer M16WKR25-271
E-11862
LH
1-1/8”
Dana/Spicer M16WKL25-304
30-1/4” 2-1/4”
E-11863
RH
Dana/Spicer M16WKR25-304
All Euclid Cam Lengths are measured from under Cam Head to beginning of Lock Ring Groove.
