BRAKE HARDWARE
BRAKE REPAIR KITS
E-4880SHD STOPMATE PLUS FRUEHAUF PRO-PAR 16-1/2” EARLY MODEL “XEM” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 1
E-3490S
Return Spring
Contains new Posi-Plus roller. For
use with the following Brake Shoe:
E-5487 (7”). Same as E-4880S
except has Heavy Duty Return
Spring.
REPLACES:
Dayton/Batco 08109030
Dayton/Batco 081127
Dayton/Batco 081135
Dayton/Batco 081711
Dana/Spicer 311A
Trailmobile 384880SHD
Haldex 66875
Trailmobile 7007202
Wagner 911018
Fruehauf ACC001996903
Haldex CQ66875
Haldex CQ68875
Fruehauf MBCBK0011
Fruehauf MBCBK0012
Meritor R507007
Sirco XK1HD
2 2
NSS*
Roll Pin
3 2
E-747
Spring Retainer
4 2
E-920S
Anchor Pin Bushing
5 1
E-1559
Cotter Pin
6 2
E-11741
Roller
7 2
E-2773
Anchor Pin
8 2
E-3007A
Roller Retainer
9 2
E-2767
Retainer Spring
E-3710HD MEGA PLUS FRUEHAUF PRO-PAR 16-1/2” LATE MODEL “XEM” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-3711
Anchor Pin
Contains new Posi-Plus roller.
For use with the following Brake
Shoes: E-3920 (7”)
REPLACES:
Dayton/Batco 08109130
Dayton/Batco 08109134
Dayton/Batco 08109138
Dayton/Batco 08109165
Dayton/Batco 081130
Dayton/Batco 081136
Dana/Spicer 34A
Trailmobile 383710
Trailmobile 383710HD
Fruehauf ACC001996923
Haldex CQ66914
Dana/Spicer HK34SD
Dana/Spicer HK34XLS
Leland K354
Hercules KIT#3
Meritor R507008
Meritor R507010
Sirco XK3MPHD
Sirco XKINT
2 2
E-8938
Anchor Pin Bushing
3 2
E-2767
Retainer Spring
4 1
E-3490B
100 lb Return Spring
5 2
E-11741
Roller
6 2
E-747
Spring Retainer
7 2
E-3227
Roller Retainer
8 1
E-1559
Cotter Pin
9 1
E-3887
Anti-Seize Compound
*Not Sold Separately
