BRAKE HARDWARE
BRAKE REPAIR KITS
E-10760 MEGA PLUS EATON 16-1/2” “ES-II” “EXTENDED” SERVICE FRONT AXLE BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-10198
Retainer Spring
For use with “ES-II” 16-1/2”
front axle shoes: E-10270 (5”),
E-10271 (6”). Can only be used
with Eaton “ES” Camshafts. Must
be used with E-10761 Horse
Collar.
REPLACES:
Dayton/Batco 08114920
Eaton 314146
Haldex CQ65446
Sirco EF2
Dana/Spicer HK62XLS
Leland K376
Meritor R507094
2 2
E-9037
Return Spring
3 2
E-5477
Roller
4 2
E-5478
Roller Retainer
E-1887AHD MEGA PLUS EATON 16-1/2” SINGLE ANCHOR PIN BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-1418
Retainer Spring
Contains Special Alloy Steel
Knurled Rollers. For use with the
following Brake Shoes: E-1778
(7”)
REPLACES:
Dayton/Batco 081122
Eaton 1001238
Trailmobile 381887AHD
Wagner 911011
Sirco EK1HD
Dana/Spicer HK24XLSLM
Hercules KIT#2
Meritor R507002
2 1
E-1428A
Return Spring
3 2
E-2217A
Roller
4 2
E-596A
Roller Pin
5 1
E-3887
Anti-Seize Compound
