BRAKE HARDWARE
BRAKE REPAIR KITS
KIT-5 MEGA PLUS FRUEHAUF (MODIFIED NO. 5) 16-1/2” EARLY MODEL BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-609
Anchor Pin
Contains new Posi-Plus roller. For
use with the following Brake Shoe:
E-2685 (7”)
REPLACES:
Dayton/Batco 081005
Dayton/Batco 08100601
Dayton/Batco 081037
Eaton 124670, 5-2241
Haldex 67434
Trailmobile 7007158
Sirco FK2, FK2HD
Leland K58
Fruehauf MBCBK0014
Meritor R507013
2 2
E-11741
Roller
3 1
E-545A
Return Spring
4 2
E-3007A
Roller Retainer
5 2
NSS*
Roll Pin
6 2
E-747
Spring Retainer
E-4515XHD STOPMATE FRUEHAUF “PROPAR” 16-1/2” LATE MODEL “XEM” BRAKE
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-3711S
Anchor Pin
Stopmate version of E-3710SHD
REPLACES:
Dayton/Batco 08109130
Dayton/Batco 08109134
Dayton/Batco 08109135
Dayton/Batco 08109165
Dayton/Batco 081136
Dayton/Batco 081713
Dana/Spicer 34A
Dana/Spicer 34ABULK
Sirco 4515XHD
Leland K136
Leland K354
Hercules KIT#3
Meritor MKT4515XHD
Dana/Spicer TA341A
Sirco XK3HD
Sirco XK3MPHD
Sirco XKINT
2 2
E-1893S
Anchor Pin Bushing
3 2
NSS*
Retainer Spring
4 1
NSS*
Return Spring
5 2
E-2177
Roller
6 2
E-747
Spring Retainer
7 2
E-3007A
Roller Retainer
E-9142 MEGA PLUS FRUEHAUF RETROFIT MERITOR “Q” BRAKE W/ECCENTRIC ANCHOR PIN 16-1/2”
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-9061
Anchor Pin
Special offset Anchor Pin allows
use of Meritor “Q” Brake Shoes on
Fruehauf Pro-Par Axles. Contains
new Posi-Plus roller. For use with
the following Brake Shoe: E-2778
(7”)
REPLACES:
Dayton/Batco 081137
Dayton/Batco 08113700
Leland K326
Meritor R507087
2 2
E-920
Anchor Pin Bushing
3 2
E-747
Spring Retainer
4 2
NSS*
Roll Pin
5 1
E-1559
Cotter Pin
6 2
E-11741
Roller
7 2
E-3007A
Roller Retainer
8 1
E-2768
Return Spring
9 2
E-2767
Retainer Spring
*Not Sold Separately
