Firestone Catalog

1T15LP-3

5795

14.7

Holland (Neway)

90557248 (replaces

90557220-1/2"NPT

flush) - ref.

W01-358-9597

W01-358-9587

BRACKET

WC1-358-3887

1T15LP-3

3162

14.5

General Coach

W01-358-9592

1T15LP-3

5795

14.7

Holland (Neway)

90557172 (AD-200) -

ref. 90557220

90557248 (1/2"NPT)

W01-358-9597

BRACKET

WC1-358-3887

1T15LP-3

3777

14.0

Holland (Neway)

90557094 (ARD

suspensions) -

reference 90557128

(bead plate-3215)

Holland (Neway)

90557128

W01-358-9599

1T15LP-3

11.4

Mack 57QL1115

Hendrickson Trailer

S14147

Supersedes

W01-358-9043

W01-358-9652

BELLOW NO.

ASSEMBLY

ORDER NO.

CROSS SECTION VIEW BEAD PLATE

TOP VIEW

PISTON

BOTTOM VIEW

ASSEMBLY

WEIGHT

(lbs.)

REPLACES

No Alignment Specified-Center Stud Mounting is Standard

Bolt or Stud 1/2-13

Combination Stud/Air Inlet Stud Outside Thread is 3/4-16

Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons

Air Inlet 1/4 N.P.T.

Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as

Hardware Key
