28 / 257
1T15LP-3
3285
17.9
Air AX (Roelofs)
W01-358-9953
1T15LP-5
5681
12.8
Holland (Neway)
90557150
W01-358-8949
1T15LP-5
5681
14.7
Holland (Neway)
90557139 (RL196-17)
(RL196A-17) -
replaces 90557122
-originally 1T15M-4
bellows
W01-358-9291
1T15LP-5
5681
13.3
Holland (Neway)
90557120 (RL196-14,
RL196A-14)
W01-358-9293
1T15LP-5
5681
11.4
Holland (Neway)
90557127
(RL-196-12)
W01-358-9294
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
27
1T Style Springs
