58 / 257
1T15M-9
3159
16.7
Holland (Neway)
90557008
90557009
90557082
Ridewell
1003589101C
Reyco 12883-01
Silent Drive
Truckstell (Marion
Mfg.) 63647
MFG.SV.# Neway
90044201
Watson & Chalin
AS-0040
W01-358-9101
SERVICE ASSEMBLY
W01-358-9102
1T15M-9
3159
15.9
Hendrickson Trailer
S6195
Holland (Neway)
90557086
90557108 (AR-90)
Watson & Chalin
AS-0038 AS-0046
Rotate Piston
90557135-28LH
Rotate Piston
90557136-28RH
W01-358-9192
SERVICE ASSEMBLY
W01-358-9102
1T15M-9
3159
16.0
Hendrickson Trailer
S2694
W01-358-9203
1T15M-9
3285
16.4
Hendrickson Trailer
S5060
W01-358-9238
1T15M-9
3404
16.6
Hendrickson Trailer
S3842
Hendrickson Can.
S10352
W01-358-9240
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
57
1T Style Springs
