Firestone Catalog

63 / 257

1T15MR-2
Holland (Neway)
90557123 - Service
assembly only (no
piston)
ARD120 & 240-5 (Air
Beam) (90054540 w/o
bracket)
W01-358-9268
CUSTOMER
SUPPLIED PISTON
1T15MT-3
16.2
Freightliner
16-14263-000
Freightliner
16-15443-000 (6033
bracket)
Freightliner
16-14263-001
Freightliner
16-15443-001 (6034
bracket)
Freightliner
16-15444-000 service
(no bracket, no
piston) --reuse old
bracket or purchase
separately (pg.62)
replacement
Freightliner
16-19470-000
16-18333-000
16-18333-001
W01-358-9634
REPLACES 1T15ZR-3
1T15MT-3
5699
14.3
Hendrickson Trailer
S20223 (HT-190T,
HS-190T) - replaces
W01-358-9630
W01-358-9640
1T15MT-3
16.0
Freightliner Custom
Chassis
16-15762-000
Ambulance
Freightliner
16-18334-000
16-19471-000
W01-358-9774
REPLACES 1T15ZR-3
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATETOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key 62
