60 / 257
1T15M-9
14.6
Watson & Chalin
W01-358-9350
1T15M-9
3404
16.5
Fruehauf UCD-9393-2
(-if bolt is removed,
this part can replace
the UCE-9393-1)
Suspensions Inc.
200041
supersedes 9241
W01-358-9394
1T15M-9
OBSOLETE
NO LONGER AVAILABLE
15.2
Bead plate Bracket
(Single Hole)
70-3582-6063
NAVISTAR
3541731C1
W01-358-9875
OBSOLETE
REPLACED BY
W01-358-1191
1T15M-9
OBSOLETE
NO LONGER AVAILABLE
15.2
Bead plate Bracket
(Double Hole)
W01-358-9876
OBSOLETE
REPLACED BY
W01-358-1190
1T15M-11
3159
17.3
Holland (Neway)
90557099
Silent Drive
W01-358-9320
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
59
1T Style Springs
