74 / 257
1T15V-11
3404
23.3
Ridewell
1003589252C
W01-358-9252
1T15V-11
3285
23.5
Oshkosh RX-08-03
W01-358-9269
1T15VP-4
5699
21.5
Hendrickson Trailer
S-25559
W01-358-8800
1T15VP-4
5699
14.3
Hendrickson S-20010
(HT230T)
ref.S21208
W01-455-9579
(different bead plate)
Also replaces
1T15VM-4.0
W01-358-9270
(REPLACES
1T15VM-4)
1T15VP-4
5699
OBSOLETE
NO LONGER AVAILABLE
14.8
Hendrickson Trailer
S-21208
W01-358-9579
OBSOLETE
REPLACED BY
W01-358-8800
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
73
1T Style Springs
