76 / 257
1T15ZR-6
16.6
Freightliner
16-13810-000
(plastic)
Freightliner
681-320-0017
(aluminum) See
W01-358-9781
Freightliner Piston
16-1673-000 (steel)
See W01-358-9782
A16-18335-000
A16-18335-001
W01-358-9780
1T15ZR-6
17.0
Freightliner
681-320-0017,
A16-14004-000
(aluminum)
A16-17574-001 (w/o
bracket)
A16-17574-002 (w/o
bracket)
Freightliner Piston
16-13840-000
(plastic) - see
W01-358-9780
Freightliner Piston
16-16773-000 (steel) -
see W01-358-9782
A16-17574-001
A16-17574-002
W01-358-9781
1T15ZR-6
20.7
Freightliner Custom
Chassis
16-16773-000 Steel
Piston
681-320-0017 Alum.
Piston See
W01-358-9781
16-13810-000 Plastic
Piston See
W01-358-9780
W01-358-9782
BRACKET
2.0
Freightliner
16-17010-001
16-15762-000
WC1-358-3874
BRACKET
2.0
Freightliner
16-17010-002
WC1-358-3876
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
75
1T Style Springs
