92 / 257
1T19L-11
5742
31.4
Granning 2598
W01-358-9214
1T19L-11
4457
22.3
Watson & Chalin
AS-0081
W01-358-9985
1T19L-12
3147
21.8
Holland (Neway)
90557200
Watson & Chalin
AS-0047
W01-358-5503
1T19L-12
24.0
Holland (Neway)
90557103
W01-358-5505
1T19L-12
3147
25.2
W01-358-5508
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
91
1T Style Springs
