94 / 257
1T19L-14
24.3
Holland (Neway)
90557104
Watson & Chalin
AS-0063
W01-358-9915
1T19L-14
4518
25.2
Holland (Neway)
90557106
W01-358-9929
1T19L-16
4518
25.5
Neway 90557144
Rotate Piston:
90557133-28 Degrees
RH 90557134-28
Degrees LH
90557148 Parallel
W01-358-9896
1T19L-16
4518
25.4
Suspensions Inc.
(Wabash)
Hendrickson Trailer
S20157
W01-358-9928
1T19LC-5
3209
21.4
Ag Chem
W01-358-8092
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
93
1T Style Springs
