Firestone Catalog

1T19LC-5

3209

14.4

John Deere

AN205761

W01-M58-8798

1T19LC-6

5742

17.9

Hendrickson Trailer

S20901 (Intraux 250)

-reuse metal disk

Hendrickson Trailer

S21784 w/ metal disk

for piston support

W01-358-8091

1T19LC-8

5361

21.2

Hendrickson Trailer

S23748 (w/disk

S24443)

W01-358-8093

1T19LE-8

5699

22.1

Tuthill Granning

700136-01

W01-358-9825

1T19LE-12

5699

22.8

Holland (Neway)

90557270 AD-130

W01-358-8793

BELLOW NO.

ASSEMBLY

ORDER NO.

CROSS SECTION VIEW BEAD PLATE

TOP VIEW

PISTON

BOTTOM VIEW

ASSEMBLY

WEIGHT

(lbs.)

REPLACES

No Alignment Specified-Center Stud Mounting is Standard

Bolt or Stud 1/2-13

Combination Stud/Air Inlet Stud Outside Thread is 3/4-16

Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons

Air Inlet 1/4 N.P.T.

Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as

Hardware Key
