11 / 68
9
Active Part Numbers
In Order by Part Number
Active Part Numbers
In Order by Size
Obsolete Part Numbers
In Order by Part Number
I – Inboard Mount
O – Outboard Mount
X – Balanced
(tp) – Patented TruPilot Feature
(a) – Unequally spaced exciter ring mounting
(b) – Equally spaced exciter ring mounting
(c) – Peripheral mount pilot
(d) – Furnished with set screw holes
(e) – Notched
(f) – For ball seat or hub piloted applications
(o) – OEM captive part number
Brake Size
Overall
Depth
Width
of Brake
Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Wheel
Type
Drum
Mount
Drum
Type
Drum
Weight
Gunite
No.
Special Information
No.
Size
16.50x7.00 10.53 7.72 8.78 11.25
10
1.00
Disc
O BEA 111
3773X
16.50x7.00 10.12 7.50 8.78 11.25
10
1.00
Disc
O BDA 107
3796X
16.50x7.00 9.00 7.81
11.25 12.75
6
0.65
Spoke
I
ABG 97
3826
16.50x7.00 9.00 7.81
11.25 12.75
5
0.78
Spoke
I
ABG 97
3826
16.50x7.00 10.82 7.70 8.78 11.25
10
1.00
Disc
O BDG 123 3889X
16.50x7.00 10.56 7.78 8.78 11.25
10
1.10
Disc
O BEA 105 3922X Use 3600AX For
O.E. Applications.
16.50x7.00 10.53 7.60 8.78 11.25
10
1.00
Disc
O BEA 99.5 4000X
Gunite Silver
Lightweight 3600AX.
16.50x7.00 7.93
7.31
11.00 12.75
6
0.65
Spoke
I
AAA 107
8656
16.50x7.00 7.93
7.31
11.00 12.75
6
0.65
Spoke
I
AAA 107
8656X
16.50x7.00 10.34 7.66 8.78 11.25
10
1.00
Disc
O BDA 94
9006X
Gunite GOLD
Optimum
Lightweight 3600AX.
16.50x7.00 9.56 7.56 9.44 11.25
10
0.84
Disc
I
BDA 90 9014X
Gunite GOLD
Optimum
Lightweight 2705X.
16.50x7.00 8.80 7.50 9.50 11.25
10
0.81
Disc
I
BBA 89 9015X
Gunite GOLD
Optimum
Lightweight 3018AX.
16.50x7.00 10.46 7.70 8.53 11.25
10
0.81
Disc
O BDA 96 9021X
Gunite GOLD
Optimum
Lightweight 3166AX.
16.50x7.00 10.10 7.34 8.53 11.25
10
0.81
Disc
O BDA 94
9022X
Gunite GOLD
Optimum
Lightweight 3699X.
16.50x7.00 10.11
7.40 8.78 11.25
10
1.00
Disc
O BDA 98 9036X
Gunite GOLD
Optimum
Lightweight 3402X.
16.50x7.00 10.50 7.85 9.00 10.82
8
1.00
Disc
O BDA 99 9041BX
Gunite GOLD
Optimum
Lightweight 3141BX.
16.50x7.00 10.50 7.85 9.00 11.25
10
1.00
Disc
O BDA 99 9041X
Gunite GOLD
Optimum
Lightweight 3141X.
16.50x8.00 11.06 8.60 8.78 11.25
10
1.00
Disc
O BDA 123
3782
16.50x8.00 11.06 8.60 8.78 11.25
10
1.00
Disc
O BDA 123 3782X
16.50x8.00 10.78 8.66 8.78 11.25
10
1.00
Disc
O BDA 105 9020X
Gunite GOLD
Optimum
Lightweight 3782X.
16.50x8.62 11.39 9.08 8.78 11.25
10
1.00
Disc
O BDA 118
3807
16.50x8.62 11.39 9.08 8.78 11.25
10
1.00
Disc
O BDA 118 3807A With brake surface
wear indicator.
16.50x8.62 11.39 9.08 8.78 11.25
10
1.00
Disc
O BDA 118 3807AX With brake surface
wear indicator.
16.50x8.62 11.39 9.08 8.78 11.25
10
1.00
Disc
O BDA 118 3807X
16.50x8.62 11.39 9.08 8.78 11.25
10
1.03
Disc
O BDA 157
3811X Heavy duty version
of 3807X.
16.50x8.62 11.46 8.90 8.78 11.25
10
0.94
Disc
O BDA 133 3890X
16.50x8.62 11.12
9.00 8.78 11.25
10
1.00
Disc
O BDA 107
9019X
Gunite GOLD
Optimum
Lightweight 3807X.
18.00x7.00 8.88 7.56 11.25 12.75
6
0.65
Spoke
I
ABB 145 2747F
18.00x7.00 8.88 7.56 11.25 12.75
6
0.78
Spoke
I
ABB 145 2747F
18.00x7.00 8.24
7.50 11.00 12.75
6
0.64
Spoke
I
AAH 148 3197X
18.00x7.00 8.20 7.40 11.25 12.75
6
0.78
Spoke
I
AAA 149 3266X
18.00x7.00 8.25 7.38 11.00 12.75
6
0.65
Spoke
I
AAA 130 3449X
(o)
Serviced by 3197X.
18.00x7.00 12.56 7.40 11.25 13.19
10
1.00
Disc
O BDA 152
3917X
18.00x7.00 10.09 7.60 8.78 11.25
10
1.00
Disc
O BCH 140 3930X
18.00x7.00 8.74
7.44 8.66 11.25
10
0.81
Disc
I
ABH 151
8685X
(o)
18.00x7.00 8.24
7.50 11.00 12.75
6
0.64
Spoke
I
ABH 148 8686X
(o)
Serviced by 3197X.
