9 / 68
7
Active Part Numbers
In Order by Part Number
Active Part Numbers
In Order by Size
Obsolete Part Numbers
In Order by Part Number
I – Inboard Mount
O – Outboard Mount
X – Balanced
(tp) – Patented TruPilot Feature
(a) – Unequally spaced exciter ring mounting
(b) – Equally spaced exciter ring mounting
(c) – Peripheral mount pilot
(d) – Furnished with set screw holes
(e) – Notched
(f) – For ball seat or hub piloted applications
(o) – OEM captive part number
Brake Size
Overall
Depth
Width
of Brake
Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Wheel
Type
Drum
Mount
Drum
Type
Drum
Weight
Gunite
No.
Special Information
No.
Size
15.00x8.62 11.90 9.30 8.78 11.25
10
1.00
Disc
O BDC 105
3744
Low profile brake
drum. Limited to a
hub mounting flange
O.D. with a max of
13.10 in.
15.00x8.62 11.90 9.30 9.00 10.82
8
1.00
Disc
O BDC 105 3744AX
Low profile brake
drum. Limited to a
hub mounting flange
O.D. with a max of
13.10 in.
15.00x8.62 11.90 9.30 8.78 11.25
10
1.00
Disc
O BDC 105 3744X
Low profile brake
drum. Limited to a
hub mounting flange
O.D. with a max of
13.10 in.
15.00x8.62 12.20 8.83 8.78 11.25
10
1.00
Disc
O BDD 112 3750BX
Low profile brake
drum, with brake
surface wear
indicator.
15.00x8.62 12.20 9.49 8.78 11.25
10
1.00
Disc
O BDD 112
3750X
15.50x5.00 9.31
5.40 8.78 11.25
10
1.00
Disc
O BEA 84 3597CX
16.50x10.00 13.34 10.50 8.54 11.25
10
0.81
Disc
O BBI
168
3475
16.50x5.00 6.12
5.38 9.25 11.25
10
0.65
Disc
I
AAA 90 2912HX
16.50x5.00 6.12
5.38 9.25 11.25
10
1.14
Disc
I
AAA 90 2912K
16.50x5.00 9.16 5.38 9.00 11.25
10
1.25
Disc
O BDA 108 2920X
Furnished with
set screw holes.
PACCAR use 3075X.
16.50x5.00 6.41
5.33 10.00 12.75
6
0.78
Spoke
I
AAG 89 3020X
(o)
Serviced by 3289X.
16.50x5.00 6.40 5.34 10.00 12.75
7
0.78
Disc
I
AAA 88 3289X
16.50x5.00 6.40 5.34 10.00 12.75
5
0.78
Spoke
I
AAA 88 3289X
16.50x5.00 6.40 5.34 10.00 12.75
6
0.78
Spoke
I
AAA 88 3289X
16.50x5.00 9.04
5.38 8.78 11.25
10
1.25
Disc
O BDA 98 3573X
(o)
Serviced by 3710X.
16.50x5.00 8.02 5.40 8.78 11.25
10
1.00
Disc
O BDA 98 3595AX
16.50x5.00 8.02 5.40 8.78 11.25
10
1.25
Disc
O BDA 98 3595X
16.50x5.00 9.34
5.40 8.78 11.25
10
1.00
Disc
O BDA 96 3598BX
16.50x5.00 9.34
5.40 8.78 11.25
10
1.25
Disc
O BDA 96 3598X
16.50x5.00 8.58 5.48 8.78 11.25
10
1.25
Disc
O BDG 84 3676AX
16.50x5.00 9.04
5.38
8.78
and
8.66
11.25
10
1.25
Disc
O BEA 96 3710X
(tp)
TruPilot brake drum.
16.50x5.00 9.37
5.43 8.78 11.25
10
1.25
Disc
O BDA 96 3758X
16.50x5.00 6.12
5.38 9.25 11.25
6
0.78
Spoke
I
AAA
81
3767X
16.50x5.00 6.69 5.35 10.00 12.75
6
0.78
Spoke
I
AAH 84
8715X
(o)
16.50x5.00 8.85 5.38 8.78 11.25
10
1.25
Disc
O BDG 80 9002X
Gunite GOLD
Optimum
Lightweight 3710X.
16.50x5.00 9.23 5.38 8.78 11.25
10
1.25
Disc
O BEA 83 9003X
Gunite GOLD
Optimum
Lightweight 3758X.
16.50x6.00 7.43 6.40 11.25 12.75
6
0.78
Spoke
I
AAA 100 3022BX
16.50x6.00 9.74
6.40 9.00 11.25
10
1.25
Disc
O BDA 109 3437X
16.50x6.00 9.74
6.52 8.78 11.25
10
1.25
Disc
O BDA 108 3687X
16.50x6.00 9.65 6.74
8.78 11.25
10
1.00
Disc
O BEA 108 3772X
16.50x6.00 9.88 6.78 9.00 11.25
10
1.25
Disc
O BDF
131
3786X
16.50x6.00 9.43 6.52 8.78 11.25
10
1.25
Disc
O BDA 87
9005X
Gunite GOLD
Optimum
Lightweight 3687X.
16.50x7.00 8.75 7.50 9.50 11.25
5
0.81
Spoke
I
ABA 100 2546C
16.50x7.00 8.75 7.50 9.50 11.25
6
0.65
Spoke
I
ABA 100 2546C
