5 / 68
3
I – Inboard Mount
O – Outboard Mount
X – Balanced
(tp) – Patented TruPilot Feature
(a) – Unequally spaced exciter ring mounting
(b) – Equally spaced exciter ring mounting
(c) – Peripheral mount pilot
(d) – Furnished with set screw holes
(e) – Notched
(f) – For ball seat or hub piloted applications
(o) – OEM captive part number
Active Part Numbers
In Order by Part Number
Active Part Numbers
In Order by Size
Obsolete Part Numbers
In Order by Part Number
Gunite
No.
Drum
Weight
Drum
Mount
Drum
Type
Wheel
Type
Brake Size
Overall
Depth
Width
of Brake
Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Special
Information
No.
Size
3295A 107
I
AAA Spoke
16.50x7.00 8.46 7.41
11.25 12.75
5/6
0.78
Serviced by
3295AX.
3295AX 107
I
AAA Spoke
16.50x7.00 8.46 7.41
11.25 12.75
5/6
0.78
3401
115
O BDA Disc
16.50x7.00 10.60 7.74
8.78 11.25
10
1.00
3401AX 115
O BDA Disc
16.50x7.00 10.60 7.74
9.00 10.82
8
1.00
3401X 115
O BDA Disc
16.50x7.00 10.60 7.74
8.78 11.25
10
1.00
3402AX 111
O BDA Disc
16.50x7.00 10.30 7.40 9.00 10.82
8
1.00
3402X 111
O BDA Disc
16.50x7.00 10.30 7.40 8.78 11.25
10
1.00
3437X 109
O BDA Disc
16.50x6.00 9.74
6.40 9.00 11.25
10
1.25
3441X
112
O BDA Disc
16.50x7.00 10.31
7.69 9.00 11.25
10
0.87
3449X
(o)
130
I
AAA Spoke
18.00x7.00 8.25 7.38 11.00 12.75
6
0.65 Serviced by 3197X.
3467B 95
I
ABD Disc
12.25x7.50 9.10 8.00 7.00 8.25
6
0.65
3475
168
O BBI
Disc
16.50x10.00 13.34 10.50 8.54
11.25
10
0.81
3485B 81
I
AAA Spoke
15.00x7.00 8.52
7.44 10.50 12.75
5/6
0.78
3557
84
I
ADA Disc
12.25x7.50 10.47
8.24
7.12
8.75
10
0.81
For 15 inch disc
wheel hubs.
3557A 84
I
ADA Disc
12.25x7.50 10.47
8.24
7.12
8.75
6
0.81
For 15 inch disc
wheel hubs.
3573X
(o)
98
O BDA Disc
16.50x5.00 9.04
5.38 8.78 11.25
10
1.25 Serviced by 3710X.
3574X 80
O BEA Disc
15.00x4.00 9.18
4.41
8.53 11.25
10
1.25
3576
131
O BDA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00 Severe duty version
of 3600A
®
.
3576X 131
O BDA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00 Severe duty version
of 3600A
®
X.
3595AX 98
O BDA Disc
16.50x5.00 8.02 5.40 8.78 11.25
10
1.00
3595X 98
O BDA Disc
16.50x5.00 8.02 5.40 8.78 11.25
10
1.25
3596BX 79
O BEH Disc
15.00x4.00 8.65 4.40 8.78 11.25
10
1.00
3596X 79
O BEH Disc
15.00x4.00 8.65 4.40 8.78 11.25
10
1.25
3597CX 84
O BEA Disc
15.50x5.00 9.31
5.40 8.78 11.25
10
1.00
3598BX 96
O BDA Disc
16.50x5.00 9.34
5.40 8.78 11.25
10
1.00
3598X 96
O BDA Disc
16.50x5.00 9.34
5.40 8.78 11.25
10
1.25
3600A 112
O BEA Disc
16.50x7.00 10.56 7.60 8.78 11.25
10
1.00 For severe duty use
3576.
3600AX 112
O BEA Disc
16.50x7.00 10.56 7.60 8.78 11.25
10
1.00 For severe duty use
3576X.
3618
104
I
ABA Disc
16.50x7.00 8.92 7.40 9.37
11.25
10
0.81
3647X
(o)
114
O BEA Disc
16.50x7.00 11.18 7.44
8.78 11.25
10
1.00 Serviced by 3757X.
3669X 53
I
AAG Spoke
15.00x4.00 5.36 4.67
9.25 11.25
5
0.78
3676AX 84
O BDG Disc
16.50x5.00 8.58 5.48 8.78 11.25
10
1.25
3687X 108
O BDA Disc
16.50x6.00 9.74
6.52 8.78 11.25
10
1.25
3691X
(o)
105
I
AAB Disc
16.50x7.00 8.50 7.44 8.66 11.25
10
0.81
Serviced by 3195X.
3699 128
O BDA Disc
16.50x7.00 10.38 7.70 8.53 11.25
10
0.81
3699X 128
O BDA Disc
16.50x7.00 10.38 7.70 8.53 11.25
10
0.81
3710X (tp)
96
O BEA Disc
16.50x5.00 9.04
5.38
8.78
and
8.66
11.25
10
1.25
TruPilot brake
drum.
3721AX
(tp)
79
O BEA Disc
15.00x4.00 8.79 4.78
8.78
and
8.66
11.25
10
1.25
TruPilot brake
drum.
3721BX 79
O BEA Disc
15.00x4.00 8.79 4.78 9.00 10.82
8
1.00
3721X
79
O BEA Disc
15.00x4.00 8.79 4.78 8.78 11.25
10
1.00
3741X
79
O BEA Disc
15.00x4.00 9.18 4.66 9.00 10.82
8
1.00
3744
105
O BDC Disc
15.00x8.62 11.90 9.30 8.78 11.25
10
1.00
Low profile brake
drum. Limited to
a hub mounting
flange O.D. with a
max of 13.10 in.
