MERITOR CLEARANCE SENSING AUTOMATIC SLACK ADJUSTERS
PART
NUMBER
BRACKET
NO.
ANGLE
STRAIGHT/
OFFSET
SPLINE
SIZE
ARM
LENGTH
BUSHING
I.D.
APPLICATION
STEER AXLE (NON-DRIVE) APPLICATIONS FOR 15”, 16-1/4”, AND 16-1/2” BRAKES
R806009
R810302 0°
Straight 1-1/4”-10 5-1/2”
5/8”
Double Bend Control Arm. For standard
steer axle brakes. Replaces 400-10001,
409-10658
R806010
R810303 0°
Straight 1-1/4”-24 5-1/2”
5/8”
Double Bend Control Arm. For standard
steer axle brakes. Replaces 400-10004,
409-10659
R806011
R810302 0°
Straight 1-1/2”-10 5-1/2”
5/8”
Double Bend Control Arm. For standard
steer axle brakes. Replaces 400-10005,
409-10662
R806012
R810302 0°
Straight 1-1/2”-28 5-1/2”
5/8”
Double Bend Control Arm. For standard
steer axle brakes. Replaces 400-10008,
409-10663
R806025
R810310 0°
Straight 1-1/2”-28 5-1/2”
1/2”
Single Bend Control Arm. For standard
steer axle brakes. Replaces 400-10008,
400-10081, 409-10228
R806502
R810302 22°
Offset
LH 5/8” 1-1/4”-10 5-1/2”
5/8”
Double Bend Control Arm. For standard
steer axle brakes with 5/8” offset arm.
Replaces 400-10003, 409-10660
R806503
R810302 22°
Offset
RH 5/8” 1-1/4”-10 5-1/2”
5/8”
Double Bend Control Arm. For standard
steer axle brakes with 5/8” offset arm.
Replaces 400-10002, 409-10661
R806504
R810303 22°
Offset
LH 5/8” 1-1/4”-24 5-1/2”
5/8”
Double Bend Control Arm. For standard
steer axle brakes with 5/8” offset arm.
Replaces 400-10041, 409-10664
R806505
R810303 22°
Offset
RH 5/8” 1-1/4”-24 5-1/2”
5/8”
Double Bend Control Arm. For standard
steer axle brakes with 5/8” offset arm.
Replaces 400-10040, 409-10665
R806500
R810304 22°
Offset
RH 1-1/2” 1-1/2”-28 5-1/2”
1/2”
Single Bend Control Arm. For Mack
16,000 lb.+ steer axle brakes with 1-1/2”
offset arm. Replaces 400-10009,
409-10599
R806501
R801304 22°
Offset
LH 1-1/2” 1-1/2”-28 5-1/2”
1/2”
Single Bend Control Arm. For Mack
16,000 lb.+ steer axle brakes with 1-1/2”
offset arm. Replaces 400-10010,
409-10600
R806507
R810311 22°
Offset
LH 5/8” 1-1/2”-28 6”
1/2”
Single Bend Control Arm. For Dina Bus
and MCI steer axle brakes. Replaces
400-10068, 409-10638
