MERITOR ASA (STROKE SENSING) SERVICE PARTS
PART NUMBER
DESCRIPTION
COMMENTS
CLEVIS PIN HELPER SPRINGS
2258-P-1238
Black
For type 9 and 12 chambers. Must be used with
R801734 clevis pin.
2258-Q-1239
Blue
PART NUMBER DIAMETER
REPLACES
APPLICATION INFORMATION
CLEVIS PIN CLIPS
2257-C-1173
3/64”
Use with 19-X-127 Clevis pin
2257-D-1174
1/16”
Use with 19-X-1084 Clevis pin
PART NUMBER LENGTH
DIAMETER
COMMENTS
COTTER PINS
K-235
5/8”
3/32”
Meritor ASA
19-X-1176
3/4”
1/16”
Stainless steel. Meritor ASA.
19-X-1175
1”
1/8”
Steel. Meritor ASA.
K-248
1”
1/8”
Meritor ASA
PART NUMBER
I.D.
O.D.
LENGTH
APPLICATION INFORMATION
BUSHINGS
1225-C-835
1/2”
5/8”
1/2”
Clevis pin bushing slack adjuster arm.
PART NUMBER
DESCRIPTION
REPLACES APPLICATION INFORMATION
GUIDE PAWL
R801700
Pull pawl assembly with curved face.
E11432 Use on all Meritor automatic
slack adjusters.
PART NUMBER
I.D.
THICKNESS
APPLICATION INFORMATION
SNAP & LOCK RINGS
1199-Y-3743
1-3/8”
3/64”
Auto Slacks
