KIMBLE MIXER
T41-12001-71
C 1.872 x 9.05
K149E
ST70-23
12000#
DuraLift & Model
9000
84001930
A 1.794 x 9.05
K123K
ST70-7
13200#
DuraLift & Model
9000
84001931
A 1.794 x 9.05
K132K
ST70-7
LINK
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
INTERNATIONAL / NAVISTAR
With Rockwell Axles:
18000# FL-901
303140C92
870148R92
B 1.999 x 10.90
KH901L
78.901.12 58.901.12
12000# FE-971
577684C91
B 1.607 x 9.37
K971R
70.971.18 50.971.18 ST70-13
12000# FF-931
FF-941
549800C91
B 1.794 x 10.40
K931L
70.931.12 50.931.12 ST70-7
12000# FF-961
02-ARV, 02-ARA
02-ARW
2505492C91
B 1.794 x 10.40
K961L
70.961.12 50.961.12 ST70-7
12000# 02-AED
02-AEG
A 1.794 x 9.05
K122E
K125E
13
70.122.05
70.125.05
13
50.122.05 ST70-7
18000# FH-931
FH-941
474520C91
B 1.999 x 11.21
KH931L
78.931.12 58.931.12 ST70-12
18000# 02-ARU
2505495C91
B 1.999 x 11.21
K180R
70.180.18 50.180.18 ST70-12
12000# FF-981
02-ARK, 02-ARL
02-ASB, 02-ASD
2500542C91
B 1.794 x 8.87
K981R
70.981.18 50.981.18 ST70-7
ISUZU
FTR
12540329
G 1.889 x 9.20
K110G
NPR
1990-1998
5-87830978-2
94058104
A 1.181 x 7.38
K68Z
NPR
1998-present
5-87831608-1
97723802
98441181
5-87832211-1
A 1.181 x 7.38
K69Z
www.stemcokaiser.com
INTERNATIONAL / NAVISTAR,
ISUZU, KENWORTH, KGI,
KIMBLE MIXER, LINK, MACK
STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 13
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
continued
KGI
15000#
