11 / 69
GMC
GMC
KODIAK - C “Series”
10000# (FM6)
B 1.794 x 10.40
K121R
8100# (FL1)
12540328
1561960
G 1.614 x 8.00
K80G
11
9000# (FM6)
11000# (FL2)
12000# (FS7)
12540329
1561961
G 1.889 x 9.20
K110G
11
14000# (FH0)
14500# (FL3)
14600# (FSD)
1990 to date
12540330
1561962
G 1.889 x 9.62
K120G
11
16000# (FH4)
88936136
B 1.999 x 11.21
K181R
ST70-12
EFA18F3
16000#
12541348
A 1.872 x 9.96
K180E
70.180.05 50.180.05 ST70-23
6000 Series
5000#
(F-050, F-055)
1973-1975
3927942
A 1.109 x 6.34
K51G
70.051.07 50.051.07
5000#
(F-050, F-055)
1975-1990
722166
A 1.179 x 6.36
K55G
70.055.07 50.055.07 ST70-4
7000# (F-070)
1973 to date
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
9000# (F-090)
1960 to date
2321013
8885021
E 1.434 x 8.75
K95G
12
70.095.07
12
50.095.07
12
11000# (F-110)
12000# (F-120)
1960 to date
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
6500 Series
7000# (F-070)
1963 to date
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
9000# (F-090)
1960 to date
2321013
8885021
E 1.434 x 8.75
K95G
12
70.095.07
12
50.095.07
12
11000# (F-110)
1960-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000# (F-120)
1963-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000# (F-120D)
1975 to date
8885621
B 1.745 x 9.37
K121G
7
70.121.07
7
50.121.07
7
7000 Series
9000# (F-090)
1960-1966
2321013
8885021
E 1.434 x 8.75
K95G
12
70.095.07
12
50.095.07
12
11000# (F-110)
1960-1966
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
7500 Series
7000# (F-070)
1966 to date
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
9000# (F-090)
1966 to date
2321013
8885021
E 1.434 x 8.75
K95G
12
70.095.07
12
50.095.07
12
11000# (F-110)
1963-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000# (F-120)
1963-1975
2264897
E 1.609 x 9.75
K125G
12
70.125.07
12
50.125.07
12
ST70-5
12000# (F-120D)
1975 to date
8885621
B 1.745 x 9.37
K121G
7
70.121.07
7
50.121.07
7
18000#(FL-901)
1970 to date
2452865
B 1.999 x 11.04
KH901L
78.901.12 58.901.12
8500 Series
7000# (F-070)
1966 to date
3838390
3927943
A 1.249 x 7.87
K70G
70.070.07 50.070.07
Steering Knuckle King Pin Kit
revision date 11/2012
Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page 8
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
continued
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
