Model
Axle
Year
OEM No.
Pin
Type
OEM Spec
Qwik Kit
TM
No.
1
Plus Kit
TM
No.
2
Econo Kit
TM
No.
Lip Seal
Installation Tool
www.stemcokaiser.com
SPICER / DANA / EATON
SPICER / DANA / EATON
E CODES
12000# E1203I
328346
328348
C 1.794 x 9.05
K123E
70.123.05 50.123.05 ST70-7
14600# E1460I/W
824530
824920
328345
328343
329404
329405
A 1.872 x 9.05
K146E
70.146.05 50.146.05 ST70-23
10000# E1002I/W
12000# E1202I/W
13200# E1322I/W
14600# E1462I/W
328347
328349
C 1.872 x 9.05
K147E
K148E
13
70.147.05 50.147.05 ST70-23
EFA CODES
12000# EFA12F3
806356
1005632
A 1.625 x 9.19
K121E
70.121.05
70.121.95
3
50.121.05 ST70-6
12000# EFA12F4
13200# EFA13F5
806355
815984
1008431
A 1.625 x 9.19
K120E
70.120.05
70.120.95
3
50.120.05 ST70-6
18000# EFA18F3,
EFA18F4
20000# EFA20F4
22000# EFA22T2,
EFA22T5
24000# EFA24T2,
EFA24T5
811525
1008500
329432
329433
329434
A 1.872 x 9.97
K180E
70.180.05 50.180.05 ST70-23
I CODES
5000# I-050
473695C91
A 1.359 x 7.97
K101I
70.101.09 50.101.09 ST70-2
6000# I-060
473695C91
A 1.359 x 7.97
K101I
70.101.09 50.101.09 ST70-2
6000# I-60S,
I-60SG, I-61
166027C91
101KK111
B 1.359 x 7.97
K102I
70.102.09 50.102.09 ST70-2
7500# I-075
473695C91
A 1.359 x 7.97
K101I
70.101.09 50.101.09 ST70-2
8000# I-080
473695C91
A 1.359 x 7.97
K101I
70.101.09 50.101.09 ST70-2
8000# I-80S
I-80SG
166027C91
101KK111
B 1.359 x 7.97
K102I
70.102.09 50.102.09 ST70-2
9000# I-090
Before Aug
1981
470752C91
483095C91
A 1.609 x 9.16
K309I
70.309.09 50.309.09 ST70-5
9000# I-090
After Aug 1981
586806C91
B 1.609 x 9.16
K310I
70.310.09 50.310.09 ST70-5
10000# I-100S,
I-100SA, I-100SG
1668411C91
B 1.921 x 9.87
K120I
8
70.120.09
8
70.120.99
3, 8
50.120.09
8
ST70-19
10800# I-108
All except
code 02309
399942C93
1658934C91
586808C91
B 1.609 x 9.66
K140I
70.140.09 50.140.09 ST70-5
10800# I-108
For code 02309
586806C91
B 1.609 x 9.16
K310I
70.310.09 50.310.09 ST70-5
12000# I-120
All except
code 02309
399942C93
1658934C91
586808C91
B 1.609 x 9.66
K140I
70.140.09 50.140.09 ST70-5
STEMCO Kaiser 4641 Industrial Dr., Millington, Michigan 48746
page19
1
.
STEMCO Kaiser Qwik Kit
TM
feature patented spiral steel bushings.
2.
STEMCO Kaiser Plus Kit
TM
feature presized steel back bronze bushings.
3.
Kit has composite bushings.
4.
Modify spindles to receive end plates.
5.
Bolt on cap.
6.
Threaded cap.
7.
Length of STEMCO Kaiser pin is 9 3/4”.
8.
STEMCO Kaiser pin is longer than OEM
9.
Torque Spec.for king pin nut 230 ft/lbs
10.
Torque Spec. for king pin nut is 300 ft/lbs.
11.
Torque Spec. for king pin nut is 406 ft/lbs.
12.
Torque Spec. for king pin nut is 350/475 ft/lbs.
13.
Includes end caps
14
.
Torque Spec. for knuckle attachment bolts is 170-200 ft/lbs.
15
Kit uses special removal tool ST90-1
A
- SINGLE LOCK FLAT
B
- DOUBLE LOCK FLAT
G
- STEP THREADED SINGLE LOCK FLAT
H
- NO LOCK FLATS
J
- SINGLE STEP
E
- TAPERED THREADED
F
- TAPERED
C
- SAME SIDE LOCK FLATS
PIN TYPE CHART:
continued
