Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
167
MIRRORS
MIR
• Stainless steel mirror head
• Arms: 16-3/4” - 24” vertical, stainless
steel finish, 13-3⁄4” - 15” horizontal,
stainless steel finish
• Ideal for most pick-up trucks, small stake
trucks and campers
• 7⁄8” hex compression nut fits heavy duty
3⁄4” tubing
• Replaces Signal-Stat 7547
Step Van Mirror
Assembly Kits
Material:
• Painted steel housing
and yoke
• Silvered glass
Replacement Parts:
97846 stainless steel
• 97847 6-1/2” x 10” flat
• 97674 6-1/2” x 6” flat
• 97848 6-1/2” x 6” convex
97669 white steel
• 97673 6-1/2” x 10” flat
• 97676 6-1/2” x 6” flat
• 97671 6-1/2” x 6” convex
Universal clamps
• 97733 head clamp
Jr. West Coast
Mirror Assembly
Kit
Material:
• Stainless steel housing
and yoke
• Silvered glass
Replacement Parts:
• 97643 mirror head
21.65 -35.43
ADJUSTABLE
9.76
• Replacement heads for Grumman Olson, Union City
Body and Utilimaster vehicles
• Silvered mirror glass resists pitting, peeling and
corrosion
• Glass is mounted in vinyl gasket
• Features a brushed stainless steel finish
• Flexible, adjustable bracket expands from 17” to
32” to fit most vehicles and offset mounting points
• Popular for use on step van and package delivery vans
• Assembly includes two mirrors – 6-1/2” x 10”
flat glass head and 6-1/2” x 6” convex glass head
• Fits to either side of the vehicle
• Mounting hardware and bracketry also included
• Replaces Signal-Stat 7580/7581
Passenger and
Cargo Van
Assembly
8-1/2” Convex
Material:
• Stainless steel
Replacement Parts:
• 97803 mirror head
• Universal tripod bracket mounts easily to most
Ford, Chevy and Dodge Vans
• Assembly includes 8” mirror head, tripod
bracket, stainless steel hardware and fasteners
• Primarily used for rear vision when backing up
vehicle
• 5/16” adjustable female ball stud and mount
• Replaces Signal-Stat 7770/7771
Step and
Commercial
Van Assembly
10-1/2” Convex
Material:
• Stainless steel
Replacement Parts:
• 97863 mirror head
• Universal mounting bracket fits on step vans
and other vehicles with flat mounting area
• Assembly includes 10-1/2” mirror head,
reinforced 3/4” O.D. tubing arm, heavy duty
mounting brackets and
stainless steel hardware
• 5/16” adjustable female
ball stud and mount
• Replaces Signal-Stat 771
16.75 - 24.00
13.75 - 15.00
5.00
10.00
8.38
17.00
13.25
2.38
10.88
13.25
16.00
2.38
10.88
13.25
16.00
97644 Jr. west coast
97846 Stainless steel
97669 White painted steel
97664 Stainless steel
97665 White
97862 Stainless steel
