MIRRORS
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
168
MIR
• Designed for conventional long nose trucks
• Bell mounts include 3” coated washers
and 3” steel washers to prevent damage to
fiberglass fenders
• Main arm expands from 22” to 31”;
top support arm expands from 14” to 21”;
bottom support arm is 12”, non-adjustable
Tripod Fender
Assembly Kit
8-1/2” Convex
Material:
• Stainless steel
bracket
• Silvered glass
Replacement Parts:
• 97829 bracket
• 97803 convex
mirror
10.00
19.00 ( x 2 )
10.00
10.50
7.50
10.00
Door/Fender
Assembly Kit
7-1/2” x 10-1/2”
Head
Material:
• Stainless steel
housing and
bracket
• Silvered glass
Replacement Parts:
• 97805 mirror head
• 97748 offset elbow
• Head can be positioned outside for wide
vehicles or inside for narrow clearances
• Mounts below eye level to improve visibility
to the front of vehicle
• Rugged stainless steel bracketry
• Kit includes mounting brackets
and instructions
• Designed for full size pick-up trucks
• Size: 7-1/2” x 10-1/2” mirror head
• Replaces Signal-Stat 7559
• Kit includes convex mirror head, nickel plated
brass compression nuts, straight and curved
arm bracket, installation instructions
• Meets NYS law 1446-2
• Designed for newer aerodynamic styled
heavy duty trucks, fitting most fiberglass,
steel and aluminum fenders and hoods
• Stainless steel construction and fasteners
Hood Mounted
Assembly Kit
8-1/2” Convex
Material:
• Stainless steel
bracket
Replacement Parts:
• 97803 convex
mirror
8.50
.3438dia.
19.00min
28.00max
19.00min
27.00max
12.00min
17.00max
Fender Mount
Assembly Kit
8-1/2” Convex
Material:
• Stainless steel
bracket
Replacement Parts:
• 97803 convex
mirror
Curvedarm
13.00min
18.00max
Straightarm
15.00min
19.00max
8.50
21.00max
14.00min
.312dia.
12.00
31.00 -
22.00
60111
97686 Tripod fender assembly
97681 Door/Fender assembly kit
97688 Hood mounted assembly kit
97687 Fender mount assembly kit
