MIRRORS
MIR
Internal Elbow
Tripod Assembly
Kit
7-1/2” x 10-1/2”
Head
Material:
• Stainless steel
housing and bracket
• Silvered glass
Replacement Parts:
• 97662 mirror head
OE Style Tripod
Assembly Kits
7-1/2” x 10-1/2”
Head
Material:
• Stainless steel
housing and bracket
• Silvered glass
Replacement Parts:
• 97805 stainless steel
mirror head
• 97660 white mirror
head
• 97869 offset elbow
Light Duty Tripod
Assembly Kit
5-1/2” x 7-1/2” Head
Material:
• Stainless steel housing and
bracket
• Silvered glass
Replacement Parts:
• 97655 mirror head
• 97869 offset elbow
• Designed for full size pick-up trucks
• Extendable for trailer towing by
swinging head out
• Glass mounted in ozone
resistant vinyl gasket
• Kit includes mounting
hardware and instructions
• Below eye level tripod bracketry
• For smaller size vehicles
• Kit includes mounting hardware
and installation instructions
• Simple, versatile, easy to mount
• Size: 5-1/2” x 7-1/2” mirror head
• Replaces Signal-Stat 7556
• Fits both right and left side of Chevy,
Ford, GMC and other pick-ups and vans
• Features “second surface” silvered
glass that resists pitting, peeling and
corrosion
• Glass is mounted in vinyl gasket
• Slotted top bracket allows assembly
to fit most light and medium duty vehicles
• Fits either the left or right side
• Assembly features bright stainless steel finish
• Includes 7-1/2” x 10-1/2” mirror, mounting
hardware and instructions
• Replaces Signal-Stat 7546/7560
10.00
19.00 (x2 )
10.00
10.50
7.50
10.00
6.00"
8.00"
2.93
10.00
5.20
14.90
10.75max
10.45
9.25min
.28dia.
3places
7.46
2.93
10.00
5.20
14.90
10.75max
10.45
9.25min
.28dia.
3places
7.46
Truck and Van
Mirror Kits
Material:
• Stainless steel housing
• Aluminum bracket
Replacement Parts:
• 7224 mirror head, RH
• 7223 mirror head, LH
• Ford F0TZ-17696B and F0TZ-17696A
• Fits F-Series Pickups, Broncos
1987-1991; Vans 1975-1991
• Door mount with swing away feature
• Aerodynamic design
• Aluminum arm
• Stainless steel is corrosion free
9.38
3.75"
15.75"
2.63
97682 Internal elbow tripod assembly kit
97678 Light duty tripod assembly kit
97680 OE style tripod assembly kit, white
97852 OE style tripod assembly kit, stainless steel
7218 Truck and van mirror kit, RH
7217 Truck and van mirror kit, LH
