BACK–UP ALARMS
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
205
ELE
4.125
5.000
3.060
2.000
3.780
.470
4x0.328
4.125
5.000
3.060
2.000
3.780
.470
4x0.328
Self-Adjusting and
Single Sound Alarm
Material:
• Rugged glass nylon housing
Specifications:
• Draws .5 amp
• Adjusts automatically to environmental
noise, reducing irritation for operators
and workers
• Sealed solid state electronics
• Meets OSHA, SAE J994 Type A - D,
Bureau of Mines and all state regulations
• Steam cleanable
• Operating temperatures range from
• -40˚F to +170˚F
• UNC terminal studs #8-32
• 2-year warranty
92905
87 to 112 db, 6-36 volts, self adjusting
92903
107 db, 6-36 volts, single sound
92904
112 db, 6-36 volts, single sound
CAUTION: Alarm must “hear”
surrounding noise levels
to properly adjust its
sound output. Mount
alarm at rear of vehicle
facing the back without
obstruction in the
listening field.
4.000
5.000
3.060
2.000
3.780
.470
4x0.328
.50
4.000
5.000
3.060
2.000
3.780
.470
4x0.328
.50
Dual Tone Alarm
Material:
• Rugged glass nylon housing
• Draws 2 amps
• Self-adjusts automatically to
produce 10 decibels (nominal) above
surrounding noise
• Depending upon how power is
applied, it can behave like a self-
adjusting alarm or a pulsed warble
sounding alarm
• Steam cleanable
• Operating temperatures range from
• -40˚F to +170˚F
• UNC terminal studs #8-32
• 2-year warranty
92927
87 to 112 db, 12-48 volts
6.063
1.750
3.031
6.063
1.750
3.031
Back-up Alarm
Switch
Material:
• Plastic or die cast
• A water-resistant switch with a 5 amp rating
• Arm operates with a full 360° movement
• For use when a back-up light circuit is not
available to activate the alarm
• For increased water resistance, an optional
3/8” ID water tight compression fitting
is available and will accommodate a 2
conductor round cable
• UL and CSA approved
• Can be wired normally open or closed
92925
Back-Up switch w/bracket, plastic
92907
Back-Up switch, die cast New
97003
3/8” ID water tight compression fitting
92925
92907
Signal-Stat
®
Back-Up Safety
Bulb and Alarm
Material:
• Metal housing
Light Source:
• 12v, 20W lamp
• Combination back-up safety device and lamp
• Provides clear 87dB “beep, beep” when vehicle is put into
reverse gear
• Installs as easily as replacing the existing bulb!
• 20 watt halogen bulb provides greater light output when
vehicle is in reverse
• Perfect for cars, school buses, vans, RVs and light trucks
• Additional safety devices safety bulbs do not meet OSHA
or SAE J994 requirements for commercial back-up alarms
328D Beeping halogen bulb, bayonet base, 87dB
(replaces 1156 bulb style), retail pack
329D Beeping halogen bulb, wedge base, 87dB
(replaces 3156 bulb style), retail pack
320
Beeping halogen bulb, 97dB
320-4 Beeping halogen bulb, 97cB, 24 volt
328D
329D
