205 / 348
BACK–UP ALARMS
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
203
ELE
Trumpet Horns
Material:
• Zinc galvanized steel
• Features trumpet horns (80 mm)
• Horns are interchangeable
• Can be mounted as horn or as theft
warning device in commercial automotive
applications
• Sound Pressure Level of 105 to 118 dB(A)
• 6A max for 12v
• Frequency: Low Tone, High Tone
• Horns can be used individually or as a pair
97360 Trumpet horn 12v, 420 Hz
97361 Trumpet horn 12v, 510 Hz
97360
4.500
1.250
3.750
4.500
4.500
1.250
3.750
4.500
• Single sound back-up alarm for light to
medium duty use
• Features epoxy sealed solid state
electronics and a rigid PVC plastic housing
• Connections are made with two #8-32
UNC terminal studs
• Meets OSHA, SAE J994, Bureau of Mines
and all state regulations
• 2-year warranty
Single Sound Alarm
Material:
• PVC plastic housing
92909 97 db, 12 volt
.343 screw hole diameter
4.1250
1.6875
2.4375
4.1250
Self-Adjusting
4” Round Alarm
Material:
• Urethane-filled housing
Recommended Accessories:
• 40700 grommet
• 94993 plug
• Features a urethane-filled housing to
protect the alarm from moisture, dust
and vibration
• Alarm is flush mounted to help protect
against road debris, salt and mud
• No additional tools required for
installation or replacement
• Uses industry standard grommets
and pigtails
• Steam cleanable
• Voltage spike protected
• Meets OSHA, SAE J994, Bureau of
Mines and all state regulations
• Operating temperatures range from
-40˚F to +170˚F
• 2-year warranty
92914
“Self-Adjusting” 77-97 db, 12-48 volts
92916
Single sound 97 db, 12volts, type ‘C’
92918
Single sound 102 db, 12-24 volts, type
Note: Self-adjusting alarm must “hear”
surrounding noise levels to properly
adjust its sound output. Mount alarm at
rear of vehicle facing the back without
obstruction in the listening field.
Requires 4.5 x 1.75 deep
mounting hole
