202 / 348
ELE
TURN SIGNAL SWITCHES
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
200
960 Series
Self-Canceling
Turn Signal Switches
Material:
• Glass filled nylon housing
Recommended Accessories:
• Modules available for washer/
wiper and headlamp functions
– contact Technical Support for
details
Note:
• 294Y200 for vehicles w/o DRL
• 294Y300 for vehicles w/DRL
• Surpasses SAE J589 and J910 standards
for turn and hazard functions
• Improved, light weight, nylon housing
and handle
• Capable of flashing 16 lamps in hazard
mode (8 lamps per side for turn signal
flashing)
• 7 speed includes 5 speed intermittent, two
speed (hi-low) or wash function
• Improved design eliminates premature
breakageand component wear
• Feature Lift-to-Dim and Flash-to-Pass
options
• Brake overrides hazard function lights when
brake pedal is depressed
91250 Self-cancel, 7 speed
91150 Self-cancel, 2 speed, hi-low
960 Series
Self-Canceling
Turn Signal Switch
Material:
• Glass filled nylon housing
• Surpasses SAE J589 and J910 standards for
turn and hazard functions
• Improved lightweight, housing and handle
• Capable of flashing 18 lamps in hazard mode
(9 lamps per side for turn signal flashing)
• Features a sealed boot to eliminate dust
intrusion
• Includes self-canceling feature
• Features a lift-to-dim/flash-to-pass
91002 Self-cancel
2.125"
3.25"
4.0"
2.875"
Turn Signal
Switches
Material:
• Die cast housing
and handle
Light Source:
• Bulb: #53
Replacement Parts:
• 9190 mounting
hardware
• 7 wire harness
• Pilot light for turn signal and hazard warning
• 16 bulb capacity for hazard warning, 8 bulbs
per side for turn signal flashing
• Recommended flasher #275 when using
LED lamps
• Recommended flasher for 12 to 16 lamps –
#183 (not included)
• Recommended flasher for 16 to 20 lamps –
#283 (not included)
• Recommended switch for trucks pulling
double or triple trailers, and for vehicles that
flash their hazard warning lamps regularly,
or for prolonged periods of time
910
Flat black, heavy load switch
