87
M/C
LED
33
®
Series
ID Assembly
Material:
• Polycarbonate lens & housing
• PVC grommet
• Nylon flange
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14 volts, 0.05 amp
FMVSS:
• P2
56"
8"
8"
8"
• US patent #6612728
• World’s smallest LED marker lamp for the transportation industry
• Hardwired lamp design is easily retrofitted
• Requires 3/4” mounting hole
• Additional part numbers availablewith extended harness lengths — call customer
service for details
33740R Red, 3 lamp grommet mount w/ .180 bullets
33741R Red, 3 lamp grommet mount, 56” w/ 2 position plug
33751R Red, 5 lamp grommet mount w/ 2 position plug
33741R
LED
33
®
Series Dual
Function Marker Lamps
Material:
• Polycarbonate lens & housing
• PVC grommet
• Nylon flange
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at 14 volts, 0.05 amp
FMVSS:
• P2
• World smallest LED marker lamp for the transportation industry
• Provides increased visibility when braking or turning
• Functions as a marker, auxiliary turn, and auxiliary stop when properly installed
• Best in class auxiliary brake function is seven times brighter than marker function
• Marker function exceeds P2 legal requirements
• Requires a 0.75 mounting hole
• Hard-wired lamp with .180 male bullet design can be easily retrofitted
• LEDs draw less current, allowing more power for other vehicle requirements
• LEDs have no filament, therefore are not susceptible to shock and vibration, a major
cause of failure for lamps with incandescent bulbs
• Engineered to withstand the toughest working environments
• Electronics sealed in epoxy to resist corrosion and moisture
• Backed by our industry-leading limited Lifetime Warranty
• Complies with FMVSS-108 marker/clearance requirements
33203R Black grommet, 12 V
33204R Black grommet (0.125-0.250), 12 V
33205R Black grommet (0.070-0.125), 12 V
33206R Black flange, 12 V
33207R Red, 3 lamp grommet mount, 56”
33208R Chrome flange, 12 V
