89
M/C
16.000
22.000
1.250
1.450
2.000
6.000
9.000
1.450
2.000
6.000
9.000
16.000
22.000
1.250
10
®
& 30
®
Series
Identification Bar
Material:
• Polycarbonate lens & housing
• Steel bar
• 14 gauge wire
Light Source:
• 12v bulb, .33 amp, 2 cp
Kit Components:
10744R or 30740R kits:
3 - 10202R or 30200R lamps
1 - 00798 ID bar w/6” centers
1 - 93906 wiring harness
10745R or 30742R kits:
3 - 10202R or 30200R lamps
1 - 00799 ID bar w/9” centers
1 - 93908 wiring harness
FMVSS:
• P2
• Features rugged blackenameled ID bar
• Lamps are mounted on 6” or 9” centers
10744R Red kit w/6” centers
10745R Red kit w/9” centers
30740R Red kit w/6” centers
30742R Red kit w/9” centers
00794 Stainless steel bar w/6” centers
.140 screw hole diameter
30740R and 30742R
.140 screw hole diameter
10744R and 10745R
16.00
1.12
2.00
7.50
7.50
26 Series
Identification Bar
Material:
• Acrylic lens
• ABS housing & bar
• 16 gauge wire
Light Source:
• Bulb: Two #193 wedge base
Replacement Parts:
• 9007 red lens
• 9007A yellow lens
FMVSS:
• P2,PC
• Uni-body housing simplifies installation & will
never rust
• Low profile styling
• Each light features two bulbs for superior visibility
& reliability
• Snap-on lens makes bulb & lens replacement easy
• Felt mounting pad is specially treated to protect
against dirt & moisture
• Replaces Truck-Lite 26743 series
• Hardwired design eliminates pin corrosion
1215
Red kit w/black finish bar
1216
Red kit w/white finish bar
1216A Yellow kit w/white finish bar
1216
9.000
6.000
23.000
17.000
16.500
22.500
1.680
1.000
LED
35
®
Series
Aluminum ID Bar
Material:
• Polycarbonate lens & housing
• Extruded aluminum bar
• 16 gauge wire
Kit Components:
35740R/Y kits:
3 - 35200R/Y LED lamps
1 - 00815 ID bar w/6” center
1 - 96989 wiring harness
35741R/Y kits:
3 - 35200R/Y LED lamps
1 - 00816 ID bar w/9” center
1 - 96996 wiring harness
FMVSS:
• P2,P3
• Designed to fit applications requiring minimal space
• Slim 1” width is perfect for upper rail mounting
• Draws less current, allowing more power for other vehicle
requirements
ID Bars - 9” centers/23” length
35741R Red kit
35741Y Yellow kit
ID Bars - 6” centers/17” length
35740R Red kit
35740Y Yellow kit
