Truck-Lite Catalog

LICENSE LAMPS

LIC

Truck-Lite Full Line Product Catalog

Customer Service: 800-562-5012 / Technical Support: 888-562-5012

Series License

Sealed

Material:

• Polycarbonate lens & housing

Light Source:

• Two bulbs designed at 14v, 0.33 amp, 2 cp each

Recommended Accessories:

• Plugs: Pages 204

• Mounting: Page 252

FMVSS:

• L

LED

Series

License Lamp

Material:

• Polycarbonate lens

• Over-molded thermoplastic resin

housing/substrate

• 20 gauge wire measuring 9 1/4”

Light Source:

• Light Emitting Diodes (LEDs)•De-

signed from 13.5v to 28v

• Current draw ranges from 0.04a to

0.05a

Recommended Accessories:

• 36710 - Gray Mounting Bracket

• 36711 - Black Mounting Bracket

• Provides License Lamp solution that requires no mounting brackets or installation screws

• Lamp adheres directly to mounting surface through use of heavy-duty adhesive backing, with an easy-to-install, peel-off liner

• Gray and black brackets are only for rear exit wire lamp, (36140C), and are available if preferred over surface mounting

• Omni-Volt•Hard-wired with rear and side exit wires complete with .180 molded bullets

• Side mount options can be mounted without any mounting brackets or fasteners

• LEDs draw much less current and are rated at 100,000 hours

• Electronics are completely sealed in epoxy to resist damage caused by moisture, corrosion, shock, and vibration

• When properly mounted the lamps are designed to conform to the applicable requirements of FMVSS - 108

36140C License, rear exit wires

36145C License, side exit wires

36710

Mounting bracket, gray

36711

Mounting bracket, black

1.20

2.490

.830

See Page 92

Series License & Utility

Sealed

Material:

• Polycarbonate lens &

housing

Light Source:

• 12v designed at 14v,

0.33 amp, 2 cp

• 24v designed at 24v,

0.17 amp, 2 cp

Recommended Accessories:

• Plugs: Pages 203-205

• Mounting: Page 258

FMVSS:

• L

• High impact polycarbonate sonically

sealed lens & housing

• Available in 12 or 24 volt versions

• Features 15,000 hour long life 12v bulb

• Must be used with 15 Series mounting

brackets shown

on page 80 & 240

• Replaces Signal-Stat 1502W

15208

Clear lamp

15209

Clear lamp, 24v

1.23

3.780

.830

19206

Clear lamp

• Fruehauf replacement lamp

• High impact polycarbonate lens

& housing are sonically sealed

• Long life 15,000 hour bulbs

• License or utility applications

• Replaces Signal-Stat 1901W

0.15 diameter male bullet

Made in the U.S.A.

36710

36140C

36710

36145C

1.88

9.25

0.75

9.25

1.88
